Sharp LC-15AV6U User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
88
LC-15AV6U
CABINET AND MECHANICAL PARTS
1 CCABAB338WJ01 J Cabinet A Ass'y BE
1-1 Not Available - Cabinet A —
1-2 HDECQA633WJSA J R/C, LED Cover AG
1-3 PSPAHA569WJ00 J Mask Spacer(Side), x2 AC
1-4 PSPAHA568WJ00 J Mask Spacer, x2 AC
1-5 TLABZA635WJZZ J "EnergyStar" Label AC
2 CCABBA772WJ01 J Cabinet B Ass'y AY
2-1 Not Available J Cabinet B —
2-2 JBTN-A567WJKA J Operation Button AL
2-3 PZETKA186WJZZ J Insulator AM
2-4 LANGTA315WJFW J Reinforcement Angle AV
2-5 XEBSN30P08000 J Screw, x1 AA
2-6 XEBSN30P12000 J Screw, x2 AA
3 CDAI-A272WJ01 J Stand Ass'y BG
3-1 GDAI-A272WJKA J Stand Base AZ
3-2 GLEGGA051WJZZ J Foot, x7 AB
3-3 MHNG-A132WJZZ J Tilt Hinge BA
3-4 XBPSN40P14JS0 J Screw, x3 AB
4 R1LK150V3GZ13Z J 15" LCD Panel Unit Ass'y DE
4-1 LANGK2949TPZZ J Bezel AW
4-2 CSLDMA960WJM1 J Back Shield Ass'y BA
4-2-1 PSLDMA960WJFW J Back Shield AS
4-2-2 LHLDZA425WJKZ J Lamp Holder-R (Bottom) AF
4-2-3 LHLDZA426WJKZ J Lamp Holder-L (Bottom) AF
4-2-4 PSHEPA228WJZZ J Reflection Sheet AL
4-2-5 TCAUZA031WJZZ J Caution Label AB
4-2-6 LHLDFA011WJKZ J PCB Holder AC
å 4-3 KLMP-A114WJLA J Lamp Unit, x4 AV
4-4 LHLDZA423WJKZ J Lamp Holder-L (Top) AK
4-5 LHLDZA424WJKZ J Lamp Holder-R (Top) AH
4-6 LX-BZA084WJF7 J Screw, x4 AA
4-7 PCOVUA046WJZZ J Diffusion Plate AV
4-8 PSHEPA227WJZZ J Diffusion Sheet, x2 AK
4-9 LHLDZ3177TPZZ J P Chassis AW
4-10 DLK00544-FPAE J Glass Panel DA
4-11 LX-HZ2002TPZZ J Screw, x5 AB
4-12 PSPAHA878WJZZ J Spacer, x4 AC
5 PSPAGA196WJZZ J PWB Spacer, x6 AC
6 PZETKA189WJKZ J Insulating Sheet, x1 AL
7 GCOVAB621WJKA J Stand Cover AP
8 GCOVAB619WJKA J Bass-Cone Cover AF
9 TLABMC150WJSA J Model Label AD
10 LANGTA281WJFW J Fixing Angle AD
11 LCHSMA305WJKA J Chassis Frame AN
12 PSLDMA964WJPZ J Shield AC
13 QPWBMD346WJPZ J Connecting Cord AQ
14 QCNW-E551WJQZ J Connecting Cord AN
15 QCNW-E549WJQZ J Connecting Cord AH
16 VSP1104PA028A J Speaker, x2 AL
17 XEBSN30P06000 J Screw, x8 AA
18 LANGTA199WJFW J AC Inlet Angle AE
19 Not Available J Serial No. Label —
20 LX-BZ3266CEFH J Screw, x2 AB
21 XBBS930P05000 J Screw, x2 AA
22 XBBS940P10000 J Screw, x5 AB
23 XEBS930P12000 J Screw, x2 AA
24 XEBS930P14000 J Screw, x5 AA
25 XEBSN30P12000 J Screw, x2 AA
26 XHPS730P08WS0 J Screw, x6 AA
27 XEBS930P10000 J Screw, x2 AA
28 PSPAHA877WJZZ J Spacer, x1 AA
