Sharp LC-19LE320 User Manual

LC-19LE320, LC-22LE320, LC-26LE320, LC-32LE320, LC-37LE320, LC-42LE320
322
NO. PARTS CODE Sharp Code DESCRIPTION
CABINET PARTS(LC-42LE320E(AUO))
1 705TZA34177 9JR7050000261 BEZEL ASSY
2 078G120A 25 M 9JR7800000029 SPEAKER 16 OHM 12W 700/400mm 130X30mm
3 KEPFAPA1 9JR9900000060 KEY PCB ASSY
4 705TZA3461A 9JR7050000146 KEY COVER ASSY
5 IRPFAPA4 9JR9900000059 IR PCB ASSY
6 750TVU420H7111N000 9JR7500000044 PANEL T420HW07 V1 TW AUO
7 CBPFA4ABPB 9JR9900000096 MAIN PCB ASSY(Nutune TUNER)
8 PTPFAPA3 9JR9900000076 RS232 PCB ASSY
9 PTPFAPA2 9JR9900000075 MEMC PCB ASSY
10 ADTVA8885PA1 9JR9900000092 POWER PCB ASSY
11 P34T0468PAT 1T0100 9JR3400000020 REAR_COVER
12 P34T0470PAT 1T0100 9JR3400000021 BASE_NECK_EU
13 705TZA34178 9JR7050000262 BASE COVER ASSY
14 P15T0737101 9JR1500000036 BRACKET_BASE
