Sharp LC-19SB14U User Manual

113
Ref. No. Part No.
★
Description Code Ref
. No. Part No.
★
Description Code
LC-19SK24U/U-W
LC-19SB24U/U-W
LC-19SB14U
LC-19D44U
C902 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C903 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C912 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C915 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1002 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1003 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1004 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1005 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1006 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1007 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1008 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1009 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1010 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1011 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1012 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1013 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1014 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1021 RC-KZA237WJZZY J 10 16V Ceramic AB
C1201 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C2001 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C2002 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C2003 VCKYCY1AB105KY J 1 10V Ceramic AB
C2007 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C2008 VCKYCY1AB105KY J 1 10V Ceramic AB
C2009 VCKYTV1CB105KY J 1 16V Ceramic AC
C2010 VCKYTV1CB105KY J 1 16V Ceramic AC
C8703 VCKYCY1AB105KY J 1 10V Ceramic AB
C8704 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C8705 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8706 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8707 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8708 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8710 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C8711 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C8712 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8713 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8714 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8715 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8716 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8717 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8718 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8719 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8720 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8721 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8722 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8723 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8726 VCCCCY1HH120JY J 12p 50V Ceramic AA
C8727 VCCCCY1HH120JY J 12p 50V Ceramic AA
C8728 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C9201 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9202 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9203 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9204 VCKYTV1HB102KY J 1000p 50V Ceramic AA
C9205 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C9206 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9207 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9208 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9210 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9211 VCKYTV1HB102KY J 1000p 50V Ceramic AA
C9212 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9213 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9217 VCKYTV1HB102KY J 1000p 50V Ceramic AA
C9225 VCKYTV1HB102KY J 1000p 50V Ceramic AA
C9227 VCKYCY1HB103KY J 0.010 50V Ceramic AA
C9228 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9229 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9230 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9302 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C9303 RC-KZA237WJZZY J 10 16V Ceramic AB
C9304 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
RESISTORS
R301 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R302 VRS-CJ1JF470JY J 47 1/16W Metal Oxide AA
R303 VRS-CZ1JF220JY J 22 1/16W Metal Oxide AA
R308 VRS-CZ1JF220JY J 22 1/16W Metal Oxide AA
R310 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R314 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R317 VRS-CZ1JF123JY J 12k 1/16W Metal Oxide AA
R318 VRS-CZ1JF182JY J 1.8k 1/16W Metal Oxide AA
R319 VRS-CZ1JF182JY J 1.8k 1/16W Metal Oxide AA
R321 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R322 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R323 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R324 VRS-CZ1JF183JY J 18k 1/16W Metal Oxide AA
R325 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R326 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R328 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R329 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R330 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R331 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R332 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R335 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R338 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R343 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R345 VRS-CZ1JF562JY J 5.6k 1/16W Metal Oxide AA
R346 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R348 VRS-CZ1JF105JY J 1.0M 1/16W Metal Oxide AA
R349 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R350 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R351 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R352 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R357 VRS-CZ1JF222JY J 2.2k 1/16W Metal Oxide AA
R401 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R402 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R403 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R404 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R405 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R406 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R407 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R408 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R409 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R410 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R411 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R412 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R414 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R415 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R416 VRS-CZ1JF104JY J 100k 1/16W Metal Oxide AA
R417 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R418 VRS-CZ1JF104JY J 100k 1/16W Metal Oxide AA
R419 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R423 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R424 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R425 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R426 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R427 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R428 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R433 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R701 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide AA
R702 VRS-CZ1JF224JY J 220k 1/16W Metal Oxide AA
R703 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R704 VRS-CZ1JF682FY J 6.8k 1/16W Metal Oxide AA
R705 VRS-CZ1JF121FY J 120 1/16W Metal Oxide AA
R706 VRS-CZ1JF222FY J 2.2k 1/16W Metal Oxide AA
R707 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R708 VRS-CZ1JF562JY J 5.6k 1/16W Metal Oxide AA
R709 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R710 VRS-CZ1JF103FY J 10k 1/16W Metal Oxide AB
R711 VRS-CZ1JF104FY J 100k 1/16W Metal Oxide AB
R712 VRS-CZ1JF223FY J 22k 1/16W Metal Oxide AA
R713 VRS-CZ1JF153FY J 15k 1/16W Metal Oxide AA
R714 VRS-CZ1JF392JY J 3.9k 1/16W Metal Oxide AA
R715 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R716 VRS-CZ1JF302JY J 3k 1/16W Metal Oxide AA
R717 VRS-CZ1JF123FY J 12k 1/16W Metal Oxide AA
R718 VRS-CZ1JF273JY J 27k 1/16W Metal Oxide AA
R719 VRS-CZ1JF154FY J 150k 1/16W Metal Oxide AA
DUNTKE367FM01
MAIN UNIT (Continued)
LC-19SB14U P109-end.indd 113 2007-9-24 9:01:09
