116
Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK24U/U-W
LC-19SB24U/U-W
LC-19SB14U
LC-19D44U
L1102 VPCEM100MR70NY J Peaking 10
µ
H AC
L1103 VPCNN220J2R9NY J Peaking 22
µ
H AB
CAPACITORS
C502 VCKYCY1HB103KY J 0.010 50V Ceramic AA
C503 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C504 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C505 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C506 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C507 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C508 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C509 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C510 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C511 VCKYCY1AB105KY J 1 10V Ceramic AB
C512 VCKYCY1AB105KY J 1 10V Ceramic AB
C513 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C514 VCKYCY1AB105KY J 1 10V Ceramic AB
C515 VCKYCY1AB105KY J 1 10V Ceramic AB
C516 VCKYCY1AB105KY J 1 10V Ceramic AB
C517 VCKYCY1AB105KY J 1 10V Ceramic AB
C518 VCKYCY1AB105KY J 1 10V Ceramic AB
C519 VCKYCY1AB105KY J 1 10V Ceramic AB
C520 VCESKA0JM107M+ J 100 6.3V Capacitor(AL) AB
C521 VCESKA0JM107M+ J 100 6.3V Capacitor(AL) AB
C524 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C525 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C527 VCKYCY1AB105KY J 1 10V Ceramic AB
C528 VCKYCY1AB105KY J 1 10V Ceramic AB
C530 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C531 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C533 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C534 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C535 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C536 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C537 VCESKA1CM107M+ J 100 16V Capacitor(AL) AC
C538 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C539 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C540 VCKYCY1AB105KY J 1 10V Ceramic AB
C541 VCKYCY1AB105KY J 1 10V Ceramic AB
C542 VCKYCY1EB104KY J 0.10 25V Ceramic AB
C543 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C1101 RC-KZA237WJZZY J 10 16V Ceramic AB
C1102 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C1103 VCKYCY1EB104KY J 0.10 25V Ceramic AB
C1104 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C1105 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1106 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1107 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1108 VCKYCY1AB105KY J 1 10V Ceramic AB
C1109 VCKYCY1AB105KY J 1 10V Ceramic AB
C1110 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1111 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1112 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1113 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1115 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1116 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1118 VCKYCY1AB105KY J 1 10V Ceramic AB
C1119 RC-KZA154WJZZY J 4.7 16V Ceramic AB
C1120 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1121 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1122 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1123 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1124 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1125 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1126 VCKYCY1HB103KY J 0.010 50V Ceramic AA
C1127 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1128 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C1129 VCKYCY1HB103KY J 0.010 50V Ceramic AA
C1130 RC-KZA154WJZZY J 4.7 16V Ceramic AB
RESISTORS
R1 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R501 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R502 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R503 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R506 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R507 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R508 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R509 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R510 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R511 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R512 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R513 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R514 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R515 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R516 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R517 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R518 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R519 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R520 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R521 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R522 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R523 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R524 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R525 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R526 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R527 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R528 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R536 VRS-CY1JF183JY J 18k 1/16W Metal Oxide AA
R537 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R538 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R539 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R540 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R541 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R542 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R543 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R544 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R545 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R546 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R547 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R548 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R549 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R550 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R551 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R552 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R553 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R554 VRS-CY1JF183FY J 18k 1/16W Metal Oxide AA
R556 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R557 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R558 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R560 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R561 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R562 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R563 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1102 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1103 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1106 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1107 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R1108 VRS-CY1JF683FY J 68k 1/16W Metal Oxide AA
R1111 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R1113 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1114 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1116 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R1117 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R1121 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R1122 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R1125 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1127 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R1132 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R1133 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1134 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1137 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
FERRITE BEADS
FB501 RBLN-A204WJZZY J Ferrite Bead AA
FB502 RBLN-A204WJZZY J Ferrite Bead AA
DUNTKE241FM01
SUB UNIT (Continued)
