120
Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK24U/U-W
LC-19SB24U/U-W
LC-19SB14U
LC-19D44U
CABINET AND MECHANICAL PARTS
LC-19SB24U/LC19SB24U-W/LC-19SB14U
1 CCABAB811WJ01 J Cabinet A Ass'y (LC-19SB24U) BD
1 CCABAB811WJ02 J Cabinet A Ass'y BD
(LC-19SB24U-W)
1 CCABAB811WJ07 J Cabinet A Ass'y BC
(LC-19SB14U)
1-1 Not Available - Cabinet A −
1-2 GCOVAC325WJ2A J SP Cover (LC-19SB24U) AQ
1-2 GCOVAC325WJ2B J SP Cover (LC-19SB24U-W) AQ
1-2 GCOVAC325WJ2C J SP Cover (LC-19SB14U) AQ
1-3 HDECQA765WJ2A J Led R/C Cover AD
1-4 PSPAHB215WJ00 J Mask Spacer(Side), x2 AB
1-5 PSPAHB216WJ00 J Mask Spacer, x2 AB
1-6 TLABZB513WJZZ J Pop Label AG
(Dleted from 3rd lot)
1-7 TLABZA635WJZZ J EnergyStar Label AC
1-8 LHLDZA867WJ2Z J SP-Holder (R) AD
1-9 LHLDZA874WJ2Z J SP-Holder (L) AD
1-10 PSPAGA378WJZZ J Gomu-Bush, x4 AB
1-11 XEBSN30P08000 J Screw For SP, x8 AA
1-12 VSP7530PA098S J Speaker, x2 AN
1-13 QCNW-G524WJQZ J For SP L/R AH
1-14 LX-HZA011WJFN J Screw For SP Holder, x2 AB
1-15 PSPAZB608WJZZ J Sponge For SP, x2 AC
1-18 PSPAHB367WJ00 J for SP(LC-19SB24U-W) AC
2 CCABBB097WJ01 J Cabinet B Ass'y BA
(LC-19SB24U/19SB14U)
2 CCABBB097WJ02 J Cabinet B Ass'y BA
(LC-19SB24U-W)
2-1 Not Available - Cabinet B −
2-2 PSPAHB320WJ00 J Mask Himelon-A AD
2-3 PSPAHB322WJ00 J Mask Himelon-B AB
3 CDAI-A375WJ01 J Stand Ass'y (LC-19SB24U) AY
3 CDAI-A375WJ02 J Stand Ass'y (LC-19SB24U-W) AY
3 CDAI-A375WJ06 J Stand Ass'y (LC-19SB14U) AY
3-1 Not Available - Stand Base −
3-2 GLEGGA062WJZZ J Foot, x6 AB
3-3 LANGHA065WJ2W J Stand Base Angle AN
3-4 SPAKPA909WJZZ J Stand PP AC
3-5 XESSN30P08000 J Screw, x5(For Base Angle) AA
4 PSLDMB150WJ01 J Main Shield Ass'y AU
4-1 Not Available - Main Shield −
4-2 Not Available - Earth Plate −
4-3 LHLDW1173CEZZ J WH For Shield, x3 AD
4-4 PSPAHB287WJ00 J Mask For Main Shield AB
4-5 PSPAZB642WJZZ J Spacer AB
4-6 PSPAHB321WJ00 J Mask for Main Shield AB
4-7 PSPAHB360WJ00 J Mask for Himelon Main Shield AA
5 LANGTA465WJ01 J VSEA Ass'y AS
5-1 Not Available - VSEA Angle −
5-2 PSPAHB266WJ00 J Mask for Vesa AB
5-3 PZETKA237WJKZ J Barrier For Vesa AE
5-4 PZETKA286WJKZ J PC For Vesa AE
6 LANGT469WJ01 J AC Inlet Angle Ass'y AH
6-1 Not Available J AC Inlet Angle −
6-2 Not Available J For AC Angle −
7 GCOVAC326WJ2A J Stand Cover AG
(LC-19SB24U/19SB14U)
7 GCOVAC326WJ2B J Stand Cover (LC-19SB24U-W) AG
8 GCOVAC327WJ2A J Bas-Conne Cover AE
(LC-19SB24U/19SB14U)
8 GCOVAC327WJ2B J Bas-Conne Cover AE
(LC-19SB24U-W)
9 GCOVAC350WJ2A J RS 232 Cover AD
(LC-19SB24U/19SB14U)
9 GCOVAC350WJ2B J RS 232 Cover AD
(LC-19SB24U-W)
10 JBTN-A675WJ2A J Control Button AF
(LC-19SB24U/19SB14U)
10 JBTN-A675WJ2B J Control Button AF
(LC-19SB24U-W)
11 LHLDW1173CEZZ J Lamp, x3 AD
12 LHLDWA092WJZZ J Wire Holder, x4 AB
13 LX-BZA202WJF7 J Screw, x13 (For PWB) AA
14 MHNG-A166WJ2Z J Hinji AV
15 PSLDMB178WJFW J Shield For Source PWB AH
16 PSPAZB626WJZZ J PC Sheet, x2 AB
17 PZETKA236WJKZ J Barrier Buttom AL
18 NSFTZ0134CEFW J For RGB 15-Dsub, x2 AD
19 PZETKA238WJKZ J Barrier for CONT-BTN AD
20 TLABMC569WJZZ J Model Label (LC-19SB24U) AD
20 TLABMC570WJZZ J Model Label (LC-19SB24U-W) AD
20 TLABMC754WJZZ J Model Label (LC-19SB14U) AH
21 XBBS940P08000 J Screw, x1(LC-19SB24U) AB
21 XBBSN40P08000 J Screw, x1(LC-19SB24U-W) AB
22 XBBS940P10000 J Screw, x4 AB
23 XBPS830P06000 J Screw, x1(LC-19SB24U) AA
23 XBPS730P06000 J Screw, x1(LC-19SB24U-W) AA
24 XEBS930P12000 J Screw, x3 AA
25 XEBS930P14000 J Screw, x9(LC-19SB24U) AA
25 XEBSN30P14000 J Screw, x9(LC-19SB24U-W) AA
26 XEBSN30P10000 J Screw, x1 AA
27 XEBSN40P10000 J Screw, x3 AB
28 R3LQ185T3GG02 J 19 LCD Panel Unit Ass'y DF
29 Not Available - Serial No. Label −
30 QCNW-G522WJQZ J Connecting Cord, AM
8pin RC Led
31 QCNW-G523WJQZ J Connecting Cord, 4 pin SW AH
32 QPWBM0242TPZZ J Connecting Cord, AG
FPC Main PWB-LCD
33 LX-BZA198WJF7 J Screw, x3 AB
34 PSPAHB360WJ00 J Mask for PWB, x6 AA
LC-19SB14U P109-end.indd 120 2007-10-6 14:48:45
