Signal: color BAR (SATURATION 75%)
Setting: 28: XGA
H: 48.36KHz V: 60Hz
SYNC: OFF
Note: Please use the color Bar of SATURATION
2
Adjusting AUTO GAIN-OFFSET in page 5 of DVP(M2-PC)to RUN .
When “AUTO GAIN-OFFSET OK” appears , this adjustment is complete
NOTE: If want to set all item to ON,please set to RUN in ADJUST PROCESS.
4.5
TEMP Adjustment
4.5.1 Receive US-10ch(JPN-8ch) the standard color bar signal
4.5.2 See if the “YDATA” reading (maximum) on Adjustment Process Page 1 is within the range in the
follow table. If not, adjust the “TEMP ALL” setting on the same page to have the “YDATA” reading
(maximum) within this range.
MODEL A3KL19SK24U
SETTING VALUE (NTSC) 96-100
Refence
(Adjustment Process Menu Page 1)
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
0 D V P 1
1
●
T A M P 1 L 9 6
2 Y D A T A 9 8
3 T A M P 1 H 1 0 0
4 T A M P A L L O F F
5 N T S C T A M P 1 7 7
6 P A L - M T A M P 6 4
7 P A L - N T A M P 6 4
To Next Page
