TROUBLESHOOTING TABLE (Continued)
<Composite video signal/S-video signal input> No video output (INPUT2)
Yes
No
No
No
Check between J503 and pin 3 and 5 of IC503.
Check between J503 and pin 1 of IC503.
Select INPUT-2 and the input signal on the input switching
menu screen.
No video output from extermal input <<INPUT-2>>
<Composite video signal input>
Is video signal sent to pin 18 of P502?
<S-video signal input>
Are Y and C signals sent to pins 15 and 14 of P502
respectively?
Check IC503 and peripheral circuits.
Check between IC503 and P502.(Q503,Q504)
Yes
No
Yes
Are signals from B16, A16, P22, P23, R22, R23, T22,
T23, U22, U23, V22, V23 of IC801 normal?
Check LCD_CONTROL PWB.
Check IC801 and peripheral circuits.
<Composite video signal input>
Is video signal fed to pin 1 of IC503?
Yes
<S-video signal input>
Are Y and C signals fed to pins 3 and 5 of IC503
respectively?
