Sharp LC-20B4M - Operation Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
76
LC-20B4M
DUNTKB769FE09 (LC-20B4M)
DUNTKB769FE12 (LC-20B4M(X))
R/C, LED UNIT
DIODES
D4008 RH-EX1283CEZZY J Zener Diode, 12V AB
D4009 RH-EX1271CEZZY J Zener Diode, 12V AB
D4010 RH-EX1271CEZZY J Zener Diode, 12V AB
RESISTORS
R4005 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R4006 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4011 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R4012 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
SWITCHES
S4701 QSW-P0035GEZZ J MAIN POWER AF
SW4002 QSW-K0108CEZZY J CH(Ù)AD
SW4003 QSW-K0108CEZZY J CH(ù)AD
SW4004 QSW-K0108CEZZY J MENU AD
SW4006 QSW-K0108CEZZY J TV/VIDEO AD
SW4007 QSW-K0108CEZZY J VOL(+) AD
SW4008 QSW-K0108CEZZY J VOL(–) AD
MISCELLANEOUS PARTS
P4001 QPLGN0563TAZZY J Plug, 5-pin(MS) AC
QCNW-A744WJZZ J Connecting Cord(MS) AE
DUNTKB770FE09 (LC-20B4M)
DUNTKB770FE12 (LC-20B4M(X))
OPERATION UNIT
TRANSISTORS
Q4001 VSDTC144EE/-1Y J DTC144EE AA
Q4003 VSDTC144EE/-1Y J DTC144EE AA
Q4007 VSUMG4N++++-1Y J UMG4N AB
DIODES
D4011 RH-PX0419CEZZY J SLEEP Indicator AC
D4012 RH-EX1271CEZZY J Zener Diode, 12V AB
D4014 RH-PX0421CEZZY J POWER Indicator AD
D4015 RH-EX1271CEZZY J Zener Diode, 12V AB
D4022 RH-EX1271CEZZY J Zener Diode, 12V AB
CAPACITORS
C4018 RC-KZ1025CEZZY J 1 10V Ceramic AB
RESISTORS
R4001 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R4021 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4023 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4024 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R4029 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P4004 QPLGN0563TAZZY J Plug, 5-pin(MR) AC
RMC4002 RRMCU0239CEZZ J R/C Sensor AG
SLD4001 PSLDM4646CEFW J Shield AD
QCNW-B310WJZZ J Connecting Cord(MR) AF
(LC-20B4M)
