Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
78
LC-20B4M
5-17 XBBSD30P05000 J Screw, x4 AA
5-18 XBBSD30P08000 J Screw, x6 AA
5-19 XEBSD20P05000 J Screw, x6 AA
5-20 XEBSD30P08000 J Screw, x1 AA
6 GCOVA2028CEKA J Terminal Cover(L) AL
7 GCOVA2038CEKA J Terminal Cover(S) AK
8 GCOVA2106CEKA J Chassis Frame AU
9 GCOVAA433WJKA J Chassis Frame Cover AG
10 GCOVAA204WJKA J Terminal Decoration Cover AD
11 LANGT9032CEFW J Fixing Metal AR
12 PMLT-0404CEZZ J Light Shielding Spacer(L) AD
13 PMLT-0405CEZZ J Light Shielding Spacer(R) AD
14
Not Available
– Serial No. Label —
15 QCNW-6058CEZZ J Connecting Cord(MA) AE
16 QCNW-A307WJZZ J Connecting Cord(VF) AD
17 QCNW-A487WJZZ J Connecting Cord(VE) AE
18 QCNW-A744WJZZ J Connecting Cord(MS) AE
19 QCNW-B321WJZZ J Connecting Cord(MB) AH
20 QCNW-B310WJZZ J Connecting Cord(MR) AF
21 LX-BZ3442CEFF J Screw, x4 AB
22 XBBSD40P06000 J Screw, x4 AA
23 XBBSF30P06000 J Screw, x2 AA
24 XBPSD30P10JS0 J Screw, x8 AA
25 XEBSD30P08000 J Screw, x7 AA
26 XEBSF40P16000 J Screw, x12 AA
1 CCABAA306WJ01 J Cabinet A Ass’y BK
1-1
Not Available
– Cabinet A —
1-2 GCOVA2020CEZZ J R/C,LED Cover AF
1-3 HBDGBA011WJSA J "SHARP" Badge AG
1-4 PSPAG0393CEUZ J Spacer, x4 AB
1-5 PSPAG0404CEZZ J SP Packing, x2 AB
1-6 PSPAG0405CEZZ J SP Packing(S), x2 AC
1-7 PSPAG0416CEZZ J SP Packing(L), x2 AC
1-8 PSPAH0678CEZZ J Spacer, x2 AA
1-9 PSPAH0699CEUZ J Spacer(S), x2 AD
1-10 PSPAH0700CEUZ J Spacer(L), x2 AD
1-11 QCNW-B398WJZZ J Connecting Cord(SP-L) AE
1-12 QCNW-B399WJZZ J Connecting Cord(SP-R) AE
1-13 VSP0050PBP98S J Speaker, x2 AR
1-14 XEBSD40P10000 J Screw, x8 AA
2 CCABBA220WJ04 J Cabinet B Ass’y(LC-20B4M) BB
2 CCABBA220WJ05 J Cabinet B Ass’y BB
(LC-20B4M(X))
2-1
Not Available
– Cabinet B —
2-2 HiNDPA435WJSA J Model Label(LC-20B4M) AG
2-2 HiNDPA440WJSA J Model Label(LC-20B4M(X)) AG
3 CDAi-A045WJ01 J Stand Ass’y BR
3-1 GDAi-A045WJSA J Stand, Base BA
3-2 CDAi-1123CE01 J Stand, Joint Ass’y BB
3-2-1
Not Available
– Stand, Joint —
3-2-2 PSPAZA083WJZZ J Spacer, x2 AB
3-3 GCOVA1945CESA J Stand Grip AK
3-4 GCOVAA251WJSA J Support Cover AM
3-5 GDAi-A062WJSA J Support AQ
3-6 GLEGGA014WJZZ J Leg, x6 AB
3-7 JHNDP0103CESA J Stand Handle AX
3-8 LANGGA016WJFW J Swivel Base AG
3-9 LX-BZA019WJFE J Screw, x2 AB
3-10 LX-NZA001WJFE J Nut, x1 AD
3-11 MHNG-A004WJFW J Hinge, x1 AU
3-12 XCBSD50P25000 J Screw, x4 AB
3-13 XCSSN50P20000 J Screw, x4 AB
3-14 XESSN40P10000 J Screw, x8 AB
3-15 XUSSD40P20000 J Screw, x4 AB
3-16 XWHSN50-16120 J Washer, x4 AB
4 CCOVAA432WJ01 J Top Cover Ass’y AS
4-1
Not Available
– Top Cover —
4-2 JBTN-A087WJKA J Operation Button AL
4-3 JBTN-A088WJKA J Power Button AF
4-4 LHLDZA027WJKZ J Power Button Holder AE
4-5 MSPRCA014WJFW J Spring, for Power Button AB
4-6 XEBSD30P08000 J Screw, x2 AA
5
Not Available
– 20" LCD Panel Unit Ass’y —
5-1 RLCDTA014WJN1 J 20" LCD Panel Unit DM
5-2
Not Available
– Back Shield Ass’y —
5-2-1 PSLDM4685CEFW J Back Shield AX
5-2-2 PMLT-0402CEZZ J Spacer AC
5-2-3 LHLDW1173CEZZ J Wire Holder AD
å 5-3 KLMP-0124CEZZ J Lamp Unit-A BH
å 5-4 KLMP-0125CEZZ J Lamp Unit-B BD
5-5 LHLDZ2176CEZZ J Lamp Fixing Holder, x2 AL
5-6 MSPRP1220CEFW J ITO Earth Spring, x1 AC
5-7 PCOVU0107CEZZ J Diffusion Panel AY
5-8 PMiR-0296CEZZ J Reflection Mirror AX
5-9 PMLT-0377CEZZ J Spacer AD
5-10 PSHEP0286CEZZ J Reflection/Deflection Sheet BP
5-11 PSHEP0287CEZZ J Prism Sheet BC
5-12 PSHEP0288CEZZ J Diffusion Sheet AQ
5-13 PSHEP0289CEZZ J ITO Sheet AY
5-14 QCNW-6054CEZZ J Connecting Cord AD
5-15 QCNW-6055CEZZ J Connecting Cord AD
5-16 QCNW-6056CEZZ J Connecting Cord AF
CABINET PARTS LOCATION
