Sharp LC-20S1E - Page 65

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
65
LC-20S1E
R6723 VRS-CY1JF824JY J 820k 1/16W Metal Oxide AA
R6724 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R6725 VRS-CY1JF824JY J 820k 1/16W Metal Oxide AA
R6726 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R6727 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R6728 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6729 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6730 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6731 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6732 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R6733 VRS-CY1JF824JY J 820k 1/16W Metal Oxide AA
R6734 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R6743 VRS-CY1JF563JY J 56k 1/16W Metal Oxide AA
R6759 VRS-TW2ED000JY J 0 1/4W Metal Oxide AB
MISCELLANEOUS PARTS
å F6700 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6701 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6702 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6703 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6704 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
FH6700 QFSHD1002CEZZ J Fuse Holder AA
FH6701 QFSHD1002CEZZ J Fuse Holder AA
FH6702 QFSHD1002CEZZ J Fuse Holder AA
FH6703 QFSHD1002CEZZ J Fuse Holder AA
FH6704 QFSHD1002CEZZ J Fuse Holder AA
FH6705 QFSHD1002CEZZ J Fuse Holder AA
FH6706 QFSHD1002CEZZ J Fuse Holder AA
FH6707 QFSHD1002CEZZ J Fuse Holder AA
FH6708 QFSHD1002CEZZ J Fuse Holder AA
FH6709 QFSHD1002CEZZ J Fuse Holder AA
P6700 QSOCFA001WJZZY J Socket, 3-pin AC
P6701 QSOCFA001WJZZY J Socket, 3-pin AC
P6702 QSOCFA001WJZZY J Socket, 3-pin AC
P6703 QSOCFA001WJZZY J Socket, 3-pin AC
P6704 QSOCFA001WJZZY J Socket, 3-pin AC
P6706 QPLGN1078GEZZ J Plug, 10-pin AC
DUNTKB983WE03
INVERTER UNIT (Continued)
DUNTKB984WE03
TUNER UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU2201 VTUVT4T5FD532 J Tuner BK
INTEGRATED CIRCUITS
IC350 VHiBH3543F+-1Y J BH3543F-E2 AE
IC1900 RH-iX1853BMZZQ J MSP3410G-QG-B8 BB
IC1901 VHiNJM4560M-1Y J NJM4560M AG
IC1902 VHiNJM4560M-1Y J NJM4560M AG
IC1903 VHiNJM4560M-1Y J NJM4560M AG
IC1904 VHiNJM4560M-1Y J NJM4560M AG
IC2201 VHiMM1506XN-1Y J MM1506XNRE AD
IC3301 VHiLA4635A+-1S J LA4635A AM
IC3500 VHiNJM4560M-1Y J NJM4560M AG
IC3701 VHiNJM2377M-1Y J NJM2377M AK
IC3702 VHiNJM2147M-1Y J NJM2147M-TE1 AF
TRANSISTORS
Q350 VSDTC144EKA-1Y J DTC144EKA AB
Q351 VSFMMT718//-1Y J FMMT718 AE
Q2201 VSUMZ1N////-1Y J UMZ1N AB
Q2202 VSUMZ1N////-1Y J UMZ1N AB
Q2203 VS2SC3928AR-1Y J 2SC3928AR AB
Q2204 VS2SC3928AR-1Y J 2SC3928AR AB
Q2205 VS2SC3928AR-1Y J 2SC3928AR AB
Q2206 VS2SC3928AR-1Y J 2SC3928AR AB
Q3300 VS2SC3928AR-1Y J 2SC3928AR AB
Q3301 VSDTC314TK/-1Y J DTC314TK AC
Q3302 VSDTA144EE/-1Y J DTA144EE AA
Q3303 VSDTC314TK/-1Y J DTC314TK AC
Q3304 VSDTC314TK/-1Y J DTC314TK AC
Q3600 VSDTC114YE/-1Y J DTC114YE AB
Q3601 VSDTC114YE/-1Y J DTC114YE AB
Q3701 VSUMH6N++++-1Y S UMH6N AB
Q3702 VSFMMT718//-1Y J FMMT718 AE
Q3703 VSFMMT718//-1Y J FMMT718 AE
Q3705 VSFMY3/////-1Y J FMY3 AB
Q3706 VS2SK2503//-1Y J 2SK2503 AE
Q3707 VSFMMT619//-1Y J FMMT619 AE
Q3708 VS2SC3928AR-1Y J 2SC3928AR AB
Q3709 VSFMY3/////-1Y J FMY3 AB
Q3901 VS2SA1530AR-1Y J 2SA1530AR AB
Q3902 VSUMZ1N////-1Y J UMZ1N AB
Q3903 VSDTC314TK/-1Y J DTC314TK AC
Q3904 VSDTC314TK/-1Y J DTC314TK AC
Q3905 VSDTC314TK/-1Y J DTC314TK AC
Q3906 VSDTC314TK/-1Y J DTC314TK AC
DIODES
D350 VHDDAN222//-1Y J Diode AA
D351 VHDMA3120WA-1Y J Diode AD
D352 VHDMA3120WA-1Y J Diode AD
D1901 RH-EX1271CEZZY J Zener Diode, 12V AB
D2201 RH-EXA101WJZZY J Zener Diode AA
D2202 RH-EX1264CEZZY J Zener Diode AB
D3300 VHDDAN222//-1Y J Diode AA
D3301 RH-EX1396CEZZY J Zener Diode, 6.8V AB
D3604 RH-EX1283CEZZY J Zener Diode, 18V AB
D3605 RH-EX1283CEZZY J Zener Diode, 18V AB
D3702 VHDDAN222//-1Y J Diode AA
D3705 VHDSFPB56//2EY J Diode AC
D3706 VHDSFPB74//2EY J Diode AD
D3707 VHDSFPB74//2EY J Diode AD
D3709 VHDDAN222//-1Y J Diode AA
D3710 VHD1SS250//1EY J Diode AB
D3711 VHDDAN222//-1Y J Diode AA
D3901 VHDDAN222//-1Y J Diode AA
D3902 VHDDAN222//-1Y J Diode AA
D3903 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D3904 RH-EX1247CEZZY J Zener Diode, 5.6V AB
