Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
66
LC-20S1E
D3905 RH-EX1271CEZZY J Zener Diode, 12V AB
D3906 RH-EX1271CEZZY J Zener Diode, 12V AB
D3907 RH-EX1271CEZZY J Zener Diode, 12V AB
D3908 RH-EX1271CEZZY J Zener Diode, 12V AB
D3909 RH-EX1271CEZZY J Zener Diode, 12V AB
D3910 RH-EX1271CEZZY J Zener Diode, 12V AB
D4008 RH-EX1283CEZZY J Zener Diode AB
D4009 RH-EX1271CEZZY J Zener Diode, 12V AB
D4010 RH-EX1271CEZZY J Zener Diode, 12V AB
D5000 RH-EX1271CEZZY J Zener Diode, 12V AB
D5001 RH-EX1271CEZZY J Zener Diode, 12V AB
D5002 RH-EX1271CEZZY J Zener Diode, 12V AB
PACKAGED CIRCUITS
X1900 RCRSB0250GEZZ J Crystal, 18.432MHz AG
COILS
L1900 VPCGM101M2R1NY J Peaking 100µH AB
L1901 VPCGM4R7MR13NYJ Peaking 4.7µH AB
L2201 VPCGM100MR25NY J Peaking 10µH AB
L2202 VP-1M5R6J1R2NY J Peaking 5.6µH AB
L2203 VP-1M3R3JR93NY J Peaking 3.3µH AB
L2204 VP-1M4R7J1R2NY J Peaking 4.7µH AB
L2205 VP-1M2R7JR85NY J Peaking 2.7µH AB
L2206 VP-1M4R7J1R2NY J Peaking 4.7µH AB
L2207 VP-1M100J1R6NY J Peaking 10µH AB
L2208 RCiLPA142WJZZ J Coil AD
L2209 VP-1M100J1R6NY J Peaking 10µH AB
L3301 RCiLFA069WJZZ J Coil AH
L3701 RCiLPA026WJZZ J Coil AD
L3702 RCiLPA144WJZZY J Coil AD
L3703 RCiLPA143WJZZY J Coil AD
L3704 RCiLPA026WJZZ J Coil AD
TRANSFORMER
å T3701 RTRNWA090WJZZY J Transformer AH
CONTROL
R3714 RVR-M0111CEZZY J 1k(B) +B Adj. AC
CAPACITORS
C350 RC-EZA126WJZZY J 47 16V Electrolytic AC
C351 RC-EZA124WJZZY J 10 16V Electrolytic AB
C352 VCKYTV1CF105ZY J 1 16V Ceramic AB
C353 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C354 VCKYTV1CF105ZY J 1 16V Ceramic AB
C355 RC-KZ0075TAZZY J 2.2 16V Ceramic AC
C356 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C357 RC-EZA126WJZZY J 47 16V Electrolytic AC
C358 RC-KZ0044TAZZY J 4.7 10V Ceramic AD
C359 RC-KZ1025CEZZY J 1 10V Ceramic AB
C360 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C361 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C370 RC-KZA043WJZZY J 10 6.3V Ceramic AC
C1900 RC-EZ0417CEZZY J 150 16V Electrolytic AD
C1901 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1902 VCCCCY1HH5R0CY J 5p 50V Ceramic AA
C1903 VCCCCY1HH5R0CY J 5p 50V Ceramic AA
C1904 RC-KZA041WJZZY J 10 10V Ceramic AC
C1905 RC-KZ1025CEZZY J 1 10V Ceramic AB
C1906 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1907 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1908 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1909 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1910 RC-KZ1025CEZZY J 1 10V Ceramic AB
C1911 RC-KZ1025CEZZY J 1 10V Ceramic AB
C1912 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1913 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1914 RC-KZ1025CEZZY J 1 10V Ceramic AB
C1915 RC-KZ1025CEZZY J 1 10V Ceramic AB
C1916 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1917 RC-EZ0417CEZZY J 150 16V Electrolytic AD
C1918 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1919 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1920 VCKYTV1CF105ZY J 1 16V Ceramic AB
C1921 RC-EZA130WJZZY J 3.3 50V Electrolytic AB
C1922 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1923 RC-KZA041WJZZY J 10 10V Ceramic AC
C1924 RC-KZA041WJZZY J 10 10V Ceramic AC
C1925 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1926 RC-EZ0417CEZZY J 150 16V Electrolytic AD
C1927 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1928 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1930 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C1931 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C1932 VCCCCY1HH101JY J 100p 50V Ceramic AA
C1933 RC-KZ0044TAZZY J 4.7 10V Ceramic AD
C1934 VCCCCY1HH101JY J 100p 50V Ceramic AA
C1935 VCKYTV1CF105ZY J 1 16V Ceramic AB
C1936 VCKYTV1CF105ZY J 1 16V Ceramic AB
C1937 RC-KZ0044TAZZY J 4.7 10V Ceramic AD
C1938 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1939 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1941 VCKYCY1CB473KY J 0.047 16V Ceramic AA
C1942 RC-KZA041WJZZY J 10 10V Ceramic AC
C1943 VCKYCY1CB473KY J 0.047 16V Ceramic AA
C1944 VCKYCY1CB473KY J 0.047 16V Ceramic AA
C1945 VCKYCY1CB473KY J 0.047 16V Ceramic AA
C1946 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1948 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1949 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1950 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1951 RC-EZA126WJZZY J 47 16V Electrolytic AC
C1952 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1953 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1956 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1957 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1960 VCKYCY1HB272KY J 2700p 50V Ceramic AA
C1961 VCKYCY1HB272KY J 2700p 50V Ceramic AA
C1963 VCKYCY1HB272KY J 2700p 50V Ceramic AA
C1964 VCKYCY1EB153KY J 0.015 25V Ceramic AA
C1965 VCKYCY1EB153KY J 0.015 25V Ceramic AA
C1967 VCKYCY1HB272KY J 2700p 50V Ceramic AA
C2201 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2202 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C2203 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2204 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2205 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2206 VCEASH1CN477MY J 470 16V Electrolytic AD
C2207 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2208 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C2209 RC-EZA128WJZZY J 1 50V Electrolytic AB
C2210 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2211 VCCCCY1HH121JY J 120p 50V Ceramic AA
C2212 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2213 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2214 VCCCCY1HH180JY J 18p 50V Ceramic AA
C2215 VCCCCY1HH121JY J 120p 50V Ceramic AA
C2216 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2217 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2218 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2219 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2220 RC-KZA041WJZZY J 10 10V Ceramic AC
C2221 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2222 VCEASH1CN477MY J 470 16V Electrolytic AD
C2223 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2224 RC-EZ1351CEZZ J 3300 6.3V Electrolytic AF
C2225 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3300 RC-EZ1274CEZZ J 1000 16V Electrolytic AD
C3301 RC-EZ1274CEZZ J 1000 16V Electrolytic AD
C3302 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3304 RC-EZA124WJZZY J 10 16V Electrolytic AB
C3305 RC-EZA127WJZZY J 100 16V Electrolytic AC
C3306 RC-KZA041WJZZY J 10 10V Ceramic AC
C3307 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3308 RC-EZA128WJZZY J 1 50V Electrolytic AB
DUNTKB984WE03
TUNER UNIT (Continued)
