Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
68
LC-20S1E
R2214 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide AA
R2215 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2216 VRS-CY1JF561JY J 560 1/16W Metal Oxide AA
R2217 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2218 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2219 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2220 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R2221 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R2222 VRS-TW2HF471JY J 470 1/2W Metal Oxide AA
R2223 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R2224 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R2225 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R2226 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2227 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2228 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2229 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R3300 VRS-TW2HF000JY J 0 1/2W Metal Oxide AA
R3301 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R3302 VRS-TW2HF000JY J 0 1/2W Metal Oxide AA
R3304 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R3305 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R3306 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3307 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3309 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3310 VRS-TW2HF000JY J 0 1/2W Metal Oxide AA
R3311 VRS-CJ1JF332JY J 3.3k 1/16W Metal Oxide AA
R3312 VRS-CJ1JF272JY J 2.7k 1/16W Metal Oxide AA
R3313 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3500 VRS-CJ1JF471JY S 470 1/16W Metal Oxide AA
R3501 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R3502 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R3503 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3504 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R3505 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R3506 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R3507 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3508 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3509 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R3510 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R3605 VRS-TW2ED000JY J 0 1/4W Metal Oxide AB
R3607 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R3701 VRS-TW2ED102JY J 1k 1/4W Metal Oxide AA
R3703 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3705 VRS-TW2ED1R0JY J 1 1/4W Metal Oxide AB
R3706 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3707 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R3708 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3709 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R3711 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R3712 VRS-CY1JF133FY J 13k 1/16W Metal Oxide AA
R3713 VRS-TW2ED102JY J 1k 1/4W Metal Oxide AA
R3715 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R3716 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R3717 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3718 VRS-CY1JF184JY J 180k 1/16W Metal Oxide AA
R3719 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R3720 VRS-TW2HF000JY J 0 1/2W Metal Oxide AA
R3722 VRS-TW2HF152JY J 1.5k 1/2W Metal Oxide AA
R3723 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3725 VRS-TW2HF152JY J 1.5k 1/2W Metal Oxide AA
R3728 VRS-TV1JD103JY J 10k 1/10W Metal Oxide AA
R3729 VRS-CY1JF1R0JY J 1 1/16W Metal Oxide AA
R3731 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3734 VRS-TQ2BD683JY J 68k 1/8W Metal Oxide AA
R3735 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3737 VRS-TW2ED561JY J 560 1/4W Metal Oxide AA
R3738 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R3739 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3740 VRS-CY1JF182FY J 1.8k 1/16W Metal Oxide AA
R3741 VRS-CY1JF122FY J 1.2k 1/16W Metal Oxide AA
R3742 VRS-CY1JF682FY J 6.8k 1/16W Metal Oxide AA
R3743 VRS-CY1JF122FY J 1.2k 1/16W Metal Oxide AA
R3744 VRS-CY1JF243FY J 24k 1/16W Metal Oxide AA
R3745 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3746 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3747 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R3748 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3749 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R3750 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3751 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R3752 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R3753 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R3754 VRS-TV1JD103JY J 10k 1/10W Metal Oxide AA
R3755 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3756 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3902 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3903 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3904 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3905 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3906 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3907 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3908 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3909 VRS-CJ1JF271JY S 270 1/16W Metal Oxide AA
R3910 VRS-CJ1JF104JY S 100k 1/16W Metal Oxide AA
R3911 VRS-CY1JF823JY J 82k 1/16W Metal Oxide AA
R3912 VRS-CJ1JF104JY S 100k 1/16W Metal Oxide AA
R3913 VRS-CJ1JF271JY S 270 1/16W Metal Oxide AA
R3914 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3915 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R3916 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3917 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3918 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3919 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3920 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3921 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3922 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R3923 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3924 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3925 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3926 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3927 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3928 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3929 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3930 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3931 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3932 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4011 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4012 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R4015 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4016 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R5000 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R5001 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R5002 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5003 VRS-CJ1JF473JY S 47k 1/16W Metal Oxide AA
R5004 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5005 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R5006 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R5007 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5008 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5009 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5010 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5012 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5013 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6518 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
SWITCHES
S4001 QSW-PA011WJZZ J MAIN POWER AF
SW4002 QSW-K0065GEZZY J CH(Ù)AD
SW4003 QSW-K0065GEZZY J CH(ù)AD
SW4004 QSW-K0065GEZZY J MENU AD
SW4006 QSW-K0065GEZZY J TV/VIDEO AD
SW4007 QSW-K0065GEZZY J VOL(+) AD
SW4008 QSW-K0065GEZZY J VOL(–) AD
MISCELLANEOUS PARTS
å F3301 QFS-D0008CEZZ J Fuse, 2A/250V AE
DUNTKB984WE03
TUNER UNIT (Continued)
