Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
69
LC-20S1E
å F3302 QFS-ZA002WJZZ J Fuse, 1.25A/250V AD
FH3301 QFSHD1002CEZZ J Fuse Holder AA
FH3302 QFSHD1002CEZZ J Fuse Holder AA
FB350 RBLN-0062TAZZY J Ferrite Bead AB
FB351 RBLN-0062TAZZY J Ferrite Bead AB
FB352 RBLN-0062TAZZY J Ferrite Bead AB
FB3300 RBLN-0254TAZZY J Ferrite Bead AB
FB3301 RBLN-0254TAZZY J Ferrite Bead AB
FB3302 RBLN-0254TAZZY J Ferrite Bead AB
FB3304 RBLN-0254TAZZY J Ferrite Bead AB
FB3305 RBLN-0254TAZZY J Ferrite Bead AB
FB3701 RBLN-0095CEZZY J Ferrite Bead AD
FB3702 RBLN-0095CEZZY J Ferrite Bead AD
FB3703 RBLN-0095CEZZY J Ferrite Bead AD
FB3705 RBLN-0051TAZZY J Ferrite Bead AC
FB3707 RBLN-0254TAZZY J Ferrite Bead AB
FB3708 RBLN-0051TAZZY J Ferrite Bead AC
FB3709 RBLN-0254TAZZY J Ferrite Bead AB
FB5000 RBLN-0062CEZZY J Ferrite Bead AC
J3300 QJAKCA010WJZZ J POWER INPUT DC 12V AF
J3900 QJAKFA021WJZZ S AUDIO OUT(L/R) AD
J5000 QSOCD0456CEZZ J S-VIDEO(AV-IN2) AE
J5001 QJAKGA038WJZZ J AUDIO(L/R)/VIDEO(AV-IN2) AE
P350 QPLGN0378GEZZ J Plug, 3-pin(TM) AB
P3301 QPLGN0478GEZZ J Plug, 3-pin(TS) AB
P3601 QPLGN1078GEZZ J Plug, 10pin AC
SC3901 QSOCN0464FJZZY J Socket, 50-pin(MA) AH
SC3902 QSOCZA056WJZZ S AV-IN1(21-pin Euro-SCART) AH
TP3300 QLUGHA006WJZZY J Lug AA
TP3301 QLUGHA006WJZZY J Lug AA
TP3701 QLUGHA006WJZZY J Lug AA
PSLDMA208WJFW J Shield AD
QCNW-B519WJQZ J Connecting Cord AH
LANGT9102CEFW J Fixing Metal AF
DUNTKB984WE03
TUNER UNIT (Continued)
DUNTKB985WE03
R/C, LED UNIT
INTEGRATED CIRCUITS
IC4201 VHiTPS850++-1Y J TPS850 AG
TRANSISTORS
Q4001 VSDTC144EE/-1Y J DTC144EE AA
Q4002 VSUMG4N++++-1Y J UMG4N AB
Q4003 VSDTC144EE/-1Y J DTC144EE AA
Q4004 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D4001 RH-PX0421CEZZY J Power/Standby/ AD
Remote Sensor Indicator
D4002 RH-PX0421CEZZY J OPC Sensor Indicator AD
D4004 RH-EX1271CEZZY J Zener Diode, 12V AB
D4005 RH-EX1271CEZZY J Zener Diode, 12V AB
D4006 RH-EX1271CEZZY J Zener Diode, 12V AB
D4007 RH-EX1271CEZZY J Zener Diode, 12V AB
D4011 RH-EX1247CEZZY J Zener Diode, 5.6V AB
CAPACITORS
C4001 RC-KZ0117TAZZY J 4.7 6.3V Ceramic AD
C4201 RC-EZA124WJZZY J 10 16V Electrolytic AB
C4202 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C4203 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R4001 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R4002 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4003 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4006 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4007 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R4009 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
J4021 QJAKJ0068CEZZ J Headphone Jack AG
P4001 QPLGN0958REZZY J Plug, 9-pin(MS) AC
P4003 QPLGN0378GEZZ J Plug, 3-pin(TM) AB
RMC4001 RRMCU0239CEZZ J R/C Receiver AG
QCNW-B780WJZZ S Connecting Cord AC
