Sharp LC-22DV510K Service Manual

104
LC-22DV510
LC-24DV510
REF No.
PARTS DESCRIPTION *
PRICE
CODE
C885 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C886 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C901 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C902 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C903 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C904 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C905 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C906 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C907 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C910 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C912 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C913 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C942 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C943 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C944 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C945 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C949 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C951 30022238 CAP SMD 33PF 50V J COG (0402) ROHS G --
C952 30022238 CAP SMD 33PF 50V J COG (0402) ROHS G --
C959 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C964 30022246 CAP SMD 150PF 50V J COG (0402) ROHS G --
C967 30022167 CAP SMD 4.7PF 50V J COG (402) ROHS G --
C968 30022165 CAP SMD 3.3PF 50V J COG (0402) RoHS G --
C970 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C971 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C972 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C973 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C974 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C990 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C997 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
R10 30070980 FERRIT SMD 220R/100Mhz 0.35R M 0.3A 402R G --
R102 30022098 RES SMD 1/16W 390R J 0402 RoHS G --
R103 30022112 RES SMD 1/16W 68K J 0402 RoHS G --
R104 30022084 RES SMD 1/16W 33K J 0402 RoHS G --
R11 30022080 RES SMD 1/16W 300R J 0402 RoHS G --
R1149 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1158 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1165 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1166 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1171 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1172 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1173 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1177 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1182 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1183 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1187 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R1198 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R12 30022060 RES SMD 1/16W 270R J 0402 ROHS G --
R1201 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R1206 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R1209 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R1221 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R1233 30022118 RES SMD 1/16W 75R J 0402 RoHS G --
R124 30000588 RES SMD 1/10W 220R J 0805 ROHS G --
R1243 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
RESISTORS
REF No.
PARTS DESCRIPTION *
PRICE
CODE
R1244 30022020 RES SMD 1/16W 560R F 0402 RoHS G --
R1245 30022020 RES SMD 1/16W 560R F 0402 RoHS G --
R1248 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R1249 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R1265 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1294 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1309 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1310 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1311 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1313 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1314 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1330 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1331 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1332 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1333 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1335 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1350 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R1355 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1356 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1357 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1358 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1364 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1365 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1366 30041373 RES NET 1/16W 22R J 8P 0402 ROHS G --
R1367 30041373 RES NET 1/16W 22R J 8P 0402 ROHS G --
R1368 30041373 RES NET 1/16W 22R J 8P 0402 ROHS G --
R1369 30041373 RES NET 1/16W 22R J 8P 0402 ROHS G --
R1370 30041373 RES NET 1/16W 22R J 8P 0402 ROHS G --
R1379 30038984 RES NET 1/32W 100R J 8P 0402 ROHS G --
R138 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R1380 30041373 RES NET 1/16W 22R J 8P 0402 ROHS G --
R1382 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1383 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1384 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1385 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1388 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1389 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R139 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R1390 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1392 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1393 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1394 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1395 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1396 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1397 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1398 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1399 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R1401 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1402 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1405 30022132 RES SMD 1/16W 0R 0402 ROHS G --
R1406 30022132 RES SMD 1/16W 0R 0402 ROHS G --
R1407 30022132 RES SMD 1/16W 0R 0402 ROHS G --
R1408 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1409 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1411 30055434 RES SMD 1/16W 62R J 0402 ROHS G --
R1412 30055434 RES SMD 1/16W 62R J 0402 ROHS G --
