Sharp LC-22DV510K Service Manual

115
LC-22DV510
LC-24DV510
REF No.
PARTS DESCRIPTION *
PRICE
CODE
R709 30046429 RES SMD 1/4W 2M F 1206 ROHS G --
R716 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R717 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R725 30007030 RES SMD 1/4W 1R J (1206) ROHS G --
R727 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R728 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R729 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R730 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R731 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R732 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R733 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R734 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R735 30007030 RES SMD 1/4W 1R J (1206) ROHS G --
R737 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R742 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R744 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R754 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R755 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R756 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R757 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R761 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R762 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R763 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R764 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R767 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R774 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
! R775 30070785 RES MG SAFE 1/2W 7.8M J NEW ROHS G --
R778 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R782 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R783 30000721 RES SMD 1/10W 4.7K J 0805 ROHS G --
R784 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R785 30012852 RES SMD 1/10W 3.9K F 0805 ROHS G --
R786 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R787 30000659 RES SMD 1/10W 330R J 0805 ROHS G --
R788 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R790 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R791 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R792 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R793 30000710 RES SMD 1/10W 47R J 0805 ROHS G --
R794 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R796 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R797 30007026 RES SMD 1/10W 5.1K J 0805 ROHS G --
R798 30000751 RES SMD 1/10W 5.6K J 0805 ROHS G --
R799 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R800 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R801 30000653 RES SMD 1/10W 33R J 0805 ROHS G --
R802 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R803 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R804 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R805 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R806 30064582 RES SMD 1/8W 18K F 0805 ROHS G --
R807 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R813 30000597 RES SMD 1/10W 22K J 0805 ROHS G --
R814 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R818 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R819 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
REF No.
PARTS DESCRIPTION *
PRICE
CODE
R820 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R822 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R824 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R825 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R826 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R827 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R828 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R829 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R830 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R831 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R832 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R833 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R834 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R838 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R841 30000631 RES SMD 1/10W 2.7K J 0805 ROHS G --
R842 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R843 30000563 RES SMD 1/10W 1.8K J 0805 ROHS G --
R848 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R849 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R850 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R851 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R852 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R853 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R854 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R855 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R856 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R857 30013199 RES SMD 1/10W 2.4K F 0805 ROHS G --
R858 30046429 RES SMD 1/4W 2M F 1206 ROHS G --
R859 30046429 RES SMD 1/4W 2M F 1206 ROHS G --
R860 30046429 RES SMD 1/4W 2M F 1206 ROHS G --
R861 30032034 RES SMD 1/8W 120K F 805 ROHS G --
R862 30000506 RES SMD 1/10W 120K J 0805 ROHS G --
! F700 30028356 FUSE SAFE 3.15A 250V (RADIAL) ROHS G --
! F701 30028356 FUSE SAFE 3.15A 250V (RADIAL) ROHS G --
J700 30002583 JUMPER WIRE 0.6MM G --
J701 30002583 JUMPER WIRE 0.6MM G --
J702 30002583 JUMPER WIRE 0.6MM G --
J703 30002583 JUMPER WIRE 0.6MM G --
J704 30002583 JUMPER WIRE 0.6MM G --
J706 30002583 JUMPER WIRE 0.6MM G --
J707 30002583 JUMPER WIRE 0.6MM G --
J708 30002583 JUMPER WIRE 0.6MM G --
J709 30002583 JUMPER WIRE 0.6MM G --
J710 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J711 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J712 30002583 JUMPER WIRE 0.6MM G --
J713 30002583 JUMPER WIRE 0.6MM G --
J714 30002583 JUMPER WIRE 0.6MM G --
J715 30002583 JUMPER WIRE 0.6MM G --
J716 30002583 JUMPER WIRE 0.6MM G --
J717 30002583 JUMPER WIRE 0.6MM G --
J718 30002583 JUMPER WIRE 0.6MM G --
J719 30002583 JUMPER WIRE 0.6MM G --
J720 30002583 JUMPER WIRE 0.6MM G --
J721 30001734 RES SMD 1/10W 0R 0805 ROHS G --
MISCELLANEOUS PARTS
