Sharp LC-22DV510K Service Manual

118
LC-22DV510
LC-24DV510
REF No.
PARTS DESCRIPTION *
PRICE
CODE
J701 30002583 JUMPER WIRE 0.6MM G --
J702 30002583 JUMPER WIRE 0.6MM G --
J703 30002583 JUMPER WIRE 0.6MM G --
J704 30002583 JUMPER WIRE 0.6MM G --
J706 30002583 JUMPER WIRE 0.6MM G --
J707 30002583 JUMPER WIRE 0.6MM G --
J708 30002583 JUMPER WIRE 0.6MM G --
J709 30002583 JUMPER WIRE 0.6MM G --
J710 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J711 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J712 30002583 JUMPER WIRE 0.6MM G --
J713 30002583 JUMPER WIRE 0.6MM G --
J714 30002583 JUMPER WIRE 0.6MM G --
J715 30002583 JUMPER WIRE 0.6MM G --
J716 30002583 JUMPER WIRE 0.6MM G --
J717 30002583 JUMPER WIRE 0.6MM G --
J718 30002583 JUMPER WIRE 0.6MM G --
J719 30002583 JUMPER WIRE 0.6MM G --
J720 30002583 JUMPER WIRE 0.6MM G --
J721 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J722 30002583 JUMPER WIRE 0.6MM G --
J723 30002583 JUMPER WIRE 0.6MM G --
J724 30002583 JUMPER WIRE 0.6MM G --
J725 30002583 JUMPER WIRE 0.6MM G --
J726 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J728 30002583 JUMPER WIRE 0.6MM G --
J729 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J730 30002583 JUMPER WIRE 0.6MM G --
P1 35000176 EYELET BR 2*3MM ROHS G --
P2 35000176 EYELET BR 2*3MM ROHS G --
P3 35000176 EYELET BR 2*3MM ROHS G --
P4 35000176 EYELET BR 2*3MM ROHS G --
! PL700 30069110 CONN HEADER SAFE 2P V0 7.92MM R/A BLKRHS G --
! PL701 30067693 CONN HEADER SAFE 2P V0 7.92MM SIDE ROHS G --
PL703 30066828 CONN PINHEADER2x10P2.54W/PLASTICSIDEROHS G --
PL706 30066919 CONN HEADER 6P 2.0MM SIDE W/LOCK RoHS G --
PL707 35016591 GROUND TERMINAL 3.5MM ROHS G --
PL708 35016591 GROUND TERMINAL 3.5MM ROHS G --
PL709 35016591 GROUND TERMINAL 3.5MM ROHS G --
PL710 35016591 GROUND TERMINAL 3.5MM ROHS G --
S702 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S705 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S711 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S733 30001735 RES SMD 1/8W 0R 1206 ROHS G --
SP1 40046710 SPACER SUPPORT TCF-12_ ROHS_V0 G --
TH701 30067963 RES THE SAFE 10R/2.3A NTC 7mm RoHS G --
! TR700 30067936 TRF SMT SAFE 17IPS60 EFD33.7 10mm ROHS G --
