Connections
A
D
E
H
I
F
G
B
Ethernet/LAN* Network connection
YPbPr HD input (Ypbpr)
AV IN Audio/Video input
SCART SCART input
HDMI 1 (ARC) HDMI input
HDMI 2 HDMI input
RF IN RF / TV Aerial Input
Digital audio Digital optical audio output
USB USB port
EARPHONE Earphone socket
CI card in Common interface module
A
J
I
B
K
H
C
D
E
F
G
2
ARC
1
RF INYPbPr IN AV IN SCART
ETHERNET
EARPHONE
CI CARD IN
OPTICAL
DIGITAL
AUDIO OUT
USB (2.0)
5V
500mA MAX
C
*The Ethernet/LAN port is used for Freeview HD services.
