CONNECTIONS
Connections
* The Ethernet/LAN port is used for Freeview HD services and smart functions.
** HDMI 2 (MHL Port) - MHL is a wired solution that allows you to access the media from your phone or
tablet onto the big screen in the highest quality.
By connecting an MHL cable (sold separately) from your mobile device and into your TV you can playback
all your videos, games and photographs directly onto your TV.
MHL simply mirrors the screen of your mobile device so will work with all applications, whilst connected it
will also charge your device too.
Ethernet/LAN* Network Connection
HDMI 1 (ARC) HDMI input
SCART SCART input
RF IN RF / TV Aerial Input
Optical Digital Audio Digital Audio output
HDMI 2 (MHL) HDMI input
2 x USB USB port
Earphone Earphone Input
CI CARD IN Common Interface module
AV IN Audio/Video Input
YPbPr HD input (Ypbpr)
A
B
C
D
ARC
ETHERNET
1
SCART
RF IN
OPTICAL
DIGITAL
AUDIO OUT
USB (2.0)
5V
500mA MAX
2
CI CARD IN
YPbPr INAV IN
EARPHONE
A
F
B
G
C
H
J
K
DE
I
E
F
G
K
H
I
J
