Sharp LC-24LE510K Service Manual

119
LC-19LE510
LC-22LE510
LC-24LE510
REF No.
PARTS
DESCRIPTION
*
PRICE
CODE
R1918 30022024 RES SMD 1/16W 12K J 0402 ROHS G --
R1919 30022024 RES SMD 1/16W 12K J 0402 ROHS G --
R1920 30022024 RES SMD 1/16W 12K J 0402 ROHS G --
R1921 30022024 RES SMD 1/16W 12K J 0402 ROHS G --
R1924 30022140 RES SMD 1/16W 22K F (0402) RoHS G --
R1925 30022140 RES SMD 1/16W 22K F (0402) RoHS G --
R1926 30022122 RES SMD 1/16W 82K J 0402 ROHS G --
R1927 30022122 RES SMD 1/16W 82K J 0402 ROHS G --
R1928 30022054 RES SMD 1/16W 20K J 0402 ROHS G --
R1929 30022054 RES SMD 1/16W 20K J 0402 ROHS G --
R1932 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R1933 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R1934 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R1939 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1940 30022028 RES SMD 1/16W 150R J 0402 RoHS G --
R1941 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1942 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1949 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R1950 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1951 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1952 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1953 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1954 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R1955 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1956 30022083 RES SMD 1/16W 330R J 0402 ROHS G --
R1957 30021977 RES SMD 1/16W 1.2K J 0402 RoHS G --
R1958 30022056 RES SMD 1/16W 220R J 0402 RoHS G --
R1959 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1960 30022088 RES SMD 1/16W 680R F 0402 ROHS G --
R1961 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
R1962 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
R209 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R221 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R222 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R223 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R231 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R252 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R3 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R344 30022003 RES SMD 1/16W 470R J 0402 ROHS G --
R384 30021999 RES SMD 1/16W 10R J 0402 RoHS G --
R473 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R474 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R483 30021977 RES SMD 1/16W 1.2K J 0402 RoHS G --
R5 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R594 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R6 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R613 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R614 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R620 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R623 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R624 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R7 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R735 30022088 RES SMD 1/16W 680R F 0402 ROHS G --
R793 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R8 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R809 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R817 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
REF No.
PARTS
DESCRIPTION
*
PRICE
CODE
R818 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R844 30021990 RES SMD 1/16W 4.7R J 0402 ROHS G --
R845 30021990 RES SMD 1/16W 4.7R J 0402 ROHS G --
R884 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R9 30070980 FERRIT SMD 220R/100Mhz 0.35R M 0.3A 402R G --
CN128 30044670 SOCKET USB SIDE RoHS G --
CN132 30059740 SOCKET D-SUB 15P TOP 11.9MM RoHS G --
CN139 30060746 CONN FFC 30P 1MM TOP LVDS ROHS G --
CN141 30067876 SOCKET PCMCIA S.DECK 4mm HEADERonly RoHS G --
CN703 30063090 CONN HEADER 5P 2.0MM SIDE W/LOCK RoHS G --
CN706 30066827 CONN FEMALE HEADER 2x10P 2.54 SIDE ROHS G --
CN707 30066018 SOCKET HDMI 19P 0.5MM TOP ROHS G --
CN708 30066018 SOCKET HDMI 19P 0.5MM TOP ROHS G --
CN710 30066919 CONN HEADER 6P 2.0MM SIDE W/LOCK RoHS G --
FS4 30064145 FUSE SAFE SMD 2A/63VDC UF 1206 RoHS G --
FS5 30062423 FUSE SAFE SMD 4A/32VDC UF HMELT 1206RoHS G --
JK10 30066835 JACK RCA 1P BLACK TOP RoHS G --
JK2 30067217 JACK HEADPHONE GREEN 3 POLE SIDE ROHS G --
JK3 30067216 JACK HEADPHONE YELLOW 3 POLE SIDE ROHS G --
JK6 30067506 JACK HEADPHONE BLACK 3 POLE SIDE ROHS G --
PL1 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
PL2 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
PL3 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
PL4 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
S1 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S101 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
S102 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
S103 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
S16 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S21 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S24 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S25 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
S49 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S5 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
S8 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S83 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S86 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S92 30022056 RES SMD 1/16W 220R J 0402 RoHS G --
S93 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S95 30022132 RES SMD 1/16W 0R 0402 ROHS G --
SC1 30070522 SOCKET SCART 21P TOP LEFT BLACK PIP ROHS G --
SW1 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
SW2 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
SW3 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
SW4 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
Z101 30012545 FILTER SAW K9656M ROHS G --
Z102 30001692 FILTER SAW OFWK3953MROHS G --
IC700 30069010 IC SMPS ICE3BR0665J 65KHz DIP8 ROHS G --
! IC701 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC702 30067808 IC PWM CONT NCP1579 SO8 ROHS G --
IC703 30066849 TR DNMOS FDS8984 7A/30V SO8 RoHS G --
INTEGRATED CIRCUITS
MISCELLANEOUS PARTS
17PW80
LC-19LE510 - POWER SUPPLY
