Sharp LC-26S7E-BK User Manual

2008-03-14
LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
169
C7113
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7114
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7117
9JR6500000282
065G120610612K 3 CHIP 10uF 16V X7R 10% 1
C7118
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7119
9JR6500000327
065G0805106A5K 3 CHIP 10uF 10V X5R 10% 1
C7120
9JR6500000261
065G060333312K Y CAP CHIP 0603 33N 16V X7R +/-10% 1
C7121
9JR6500000321
065G060322412K Y CAP CHIP 0603 220N 16V X7R 10% 1
C7122
9JR6500000177
065G060322131J Y CAP CHIP 0603 220P 50V NPO +/-5% 1
C7123
9JR6500000258
065G060322232K Y CAP CHIP 0603 2N2 50V X7R +/-10% 1
C7124
9JR6500000206
065G080533132K Y CAP CHIP 0805 330PF K 50V X7R 1
C7125
9JR6500000282
065G120610612K 3 CHIP 10uF 16V X7R 10% 1
C7126
9JR7100000051
067G215Y2212CT EC 220uF 10V GL 6.3x11mm 1
C7127
9JR7100000051
067G215Y2212CT EC 220uF 10V GL 6.3x11mm 1
C7129
9JR7100000047
067G 3152214KT EC 220UF 25V ED 8*12mm 1
C7131
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7132
9JR6700000161
067G 3051007ET EC 10uF 50V RGA 5x11 mm 1
C7133
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7134
9JR6700000162
067G 3051012ET EC 100uF 10V RGA 5x11mm 1
C7136
9JR7100000046
067G 3054716ET EC 470uF 35V RGA 10x16mm 1
C7137
9JR6500000320
065G060322312K Y CAP CHIP 0603 22N 16V X7R +/-10% 1
C7138
9JR6500000177
065G060322131J Y CAP CHIP 0603 220P 50V NPO +/-5% 1
C7139
9JR6500000258
065G060322232K Y CAP CHIP 0603 2N2 50V X7R +/-10% 1
C7140
9JR6500000324
065G060333132K Y CAP CHIP 0603 330PF K 50V X7R 1
C7141
9JR6500000321
065G060322412K Y CAP CHIP 0603 220N 16V X7R 10% 1
C7143
9JR6700000162
067G 3051012ET EC 100uF 10V RGA 5x11mm 1
C7156
9JR6700000161
067G 3051007ET EC 10uF 50V RGA 5x11 mm 1
C7157
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7158
9JR6500000282
065G120610612K 3 CHIP 10uF 16V X7R 10% 1
C7159
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7160
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7161
9JR6700000161
067G 3051007ET EC 10uF 50V RGA 5x11 mm 1
C7162
9JR6700000134
067G215Y1013KT LOW ESR EC 100uF 16V 6.3*11mm 1
C7163
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7164
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7201
9JR6500000326
065G080510527Z Y CAP CHIP 0805 1U 25V Y5V -20%+80% 1
C7204
9JR6500000164
065G060310437Z Y CAP CHIP 0603 100N 50V Y5V -20%+80% 1
C7206
9JR6500000164
065G060310437Z Y CAP CHIP 0603 100N 50V Y5V -20%+80% 1
C7207
9JR6700000160
067G 2154714CT EC 470uF 25V GF 10x12mm 1
C7209
9JR6500000164
065G060310437Z Y CAP CHIP 0603 100N 50V Y5V -20%+80% 1
C7210
9JR6700000163
067G 305471 7C EC 470uF 50V KM 10x20mm 1
C7212
9JR6500000164
065G060310437Z Y CAP CHIP 0603 100N 50V Y5V -20%+80% 1
C7213
9JR7100000045
067G 3052214CT EC 220UF/25V KM 8*11mm 1
C7301
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7302
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
C7304
9JR6500000237
065G040233031J Y CAP CHIP 0402 33P 50V NPO +/-5% 1
C7306
9JR6500000233
065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 1
CN1201
9JR8800000031
088G 78 13942 C RCA JACK 1*5 G/B/R/W/R AV5-8.4-02-01 1
CN1204
9JR8800000069
088G302A12 YG PHONE JACK 3.5mm 7P BLACK 2SJ1508-001111 1
CN1205
9JR8800000047
088G 78 13938 YG RCA JACK 1*3 Y/W/R V/A RCA-346D-03 1
CN1206
9JR8800000030
088G 78 13934 C RCA JACK 1*3 Y/W/R AV3-8.4-13-1 1
CN1401
9JR8800000068
088G 35315FVSC D-SUB 15PIN VERTICAL CONN WITH SCREW 1
CN1501
9JR8800000067
088G 340A19 YG HDMI HEADER 19P HDMI-003 1
CN1601
9JR8800000041
088G 34019E VD HDMI HEADER 19P HDM24A-19BM4YN10 1

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
