Sharp LC-26S7E-BK User Manual

LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
180
R7139
9JR6100000352
061G0603563 T RST CHIP 56K 1/10W 5% 1
R7140
9JR6100000535
061G06031200FT RST CHIP 120R 1/10W 1% 1
R7141
9JR6100000682
061G06032000FT RST CHIP 200R 1/10W 1% 1
R7201
9JR6100000342
061G0402472 T RST CHIP 4K7 1/16W 5% 1
R7203
9JR6100000399
061G0402103 T RST CHIP 10K 1/16W 5% 1
R7205
9JR6100000287
061G0603103 T RST CHIP 10K 1/10W 5% 1
R7206
9JR6100000289
061G0603222 T RST CHIP 2K2 1/10W 5% 1
R7208
9JR6100000285
061G0603101 T RST CHIP 100R 1/10W 5% 1
R7209
9JR6100000287
061G0603103 T RST CHIP 10K 1/10W 5% 1
R7213
9JR6100000684
061G0603223 T RST CHIP 22K 1/10W 5% 1
R7214
9JR6100000398
061G0402470 T RST CHIP 47R 1/16W 5% 1
R7215
9JR6100000400
061G0402000 T RST CHIP MAX 0R05 1/16W 1
R7217
9JR6100000342
061G0402472 T RST CHIP 4K7 1/16W 5% 1
R7301
9JR6100000343
061G0402479 T RST CHIP 4R7 1/16W 5% 1
R7302
9JR6100000343
061G0402479 T RST CHIP 4R7 1/16W 5% 1
R7303
9JR6100000400
061G0402000 T RST CHIP MAX 0R05 1/16W 1
R7310
9JR6100000400
061G0402000 T RST CHIP MAX 0R05 1/16W 1
R7319
9JR6100000398
061G0402470 T RST CHIP 47R 1/16W 5% 1
R7320
9JR6100000673
061G0402101 T RST CHIP 100R 1/16W 5% 1
R7321
9JR6100000673
061G0402101 T RST CHIP 100R 1/16W 5% 1
R7322
9JR6100000673
061G0402101 T RST CHIP 100R 1/16W 5% 1
R7513
9JR6100000400
061G0402000 T RST CHIP MAX 0R05 1/16W 1
R7527
9JR6100000296
061G0603000 T RST CHIP MAX 0R05 1/10W 1
RP4401
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
RP4402
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
RP4403
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
RP4404
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
RP4405
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
RP4406
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
RP4407
9JR6100000326
061G 126470 8Y RST CHIP AR 8P4R 47 OHM +-5% 1/16W 1
TU1101
9JR9400000003
094GPASEALL10G TUNER PAL+SECAM TAFT-S710D 1
U1101
9JR5600000124
056G 563963 IC SC4215ASTRT SO-8 1
U1201
9JR5600000120
056G 192901 IC DRV601RTJR QFN-20 1
U1401
9JR5600000100
056G1133 34 M24C02-WMN6TP 1
U1501
9JR5600000100
056G1133 34 M24C02-WMN6TP 1
U1503
9JR5600000062
056G 634 24 IC TMDS261PAGT TQFP-64 1
U1602
9JR5600000100
056G1133 34 M24C02-WMN6TP 1
U1701
9JR5600000078
056G 623906 IC NLASB3157DFT2G SC-88 1
U1702
9JR5600000078
056G 623906 IC NLASB3157DFT2G SC-88 1
U1801
9JR5600000125
056G 665918 IC STMPS2171STR SOT23-5L 1
U1901
9JR5600000120
056G 192901 IC DRV601RTJR QFN-20 1
U4101
9JR5600000126
056G1125195 IC WT6703F-SG240WT SOP-24 1
U4102
9JR5600000063
056G 643906 IC APX809-26SAG-7 SOT23 1
U4201
9JR5600000127
056G1126 62 IC MST9A885GL-LF LQFP-256 1
U4202
9JR5600000064
056G 643A03 IC APX810-29SAG-7 SOT23 1
U4203
9JR5600000129
056G113353A IC M24C32-WMN6T SO-8 ST 1
U4401
9JR5600000060
056G 615924 IC W9412G6IH-5 TSSOP-66 1
U4402
9JR5600000128
056G1133 97 IC MX25L1605DM2I-12G 16Mb SOP-8 1
U6101
9JR5600000120
056G 192901 IC DRV601RTJR QFN-20 1
U6102
9JR5600000061
056G 616917 IC TPA3124D2PWPR 1
U6103
9JR5600000120
056G 192901 IC DRV601RTJR QFN-20 1
U7101
9JR5600000121
056G 368906 IC TPS62203DBVR SOT-23 1
U7103
9JR5600000123
056G 563952 IC SC4524BSETRT SO-8 1

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
