Sharp LC-26S7E-BK User Manual

2008-03-14
LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
185
1112 9JR9900000029 IRPF9PB4 IR PCB ASSY 1
U001
9JR5600000021
056T 627902 IC TSOP34438ST1 1
CN001
9JR3300000036
033G8032 5F X WAFER 5P 1.25MM S1315-05RVB-S01-K 1
Q001
9JR5700000002
057G 419513 BC847C 1
Q002
9JR5700000002
057G 419513 BC847C 1
R006
9JR6100000285
061G0603101 T RST CHIP 100R 1/10W 5% 1
R001
9JR6100000286
061G0603102 T RST CHIP 1K 1/10W 5% 1
R007
9JR6100000287
061G0603103 T RST CHIP 10K 1/10W 5% 1
R008
9JR6100000287
061G0603103 T RST CHIP 10K 1/10W 5% 1
R002
9JR6100000288
061G0603221 T RST CHIP 220R 1/10W 5% 1
R003
9JR6100000289
061G0603222 T RST CHIP 2K2 1/10W 5% 1
R004
9JR6100000289
061G0603222 T RST CHIP 2K2 1/10W 5% 1
R005
9JR6100000290
061G0603272 T RST CHIP 2K7 1/10W 5% 1
C003
9JR6500000164
065G060310437Z Y CAP CHIP 0603 100N 50V Y5V -20%+80% 1
C001
9JR6500000165
065G0603105A7Z Y CAP CHIP 0603 1U 10V Y5V -20%+80% 1
LED001
9JR8100000001
081T 14908 KB LED SM KPB-3025SURKCGKC 1
1114 9JR9900000030 KEPF9PA8 KEY PCB ASSY 1
C016 9JR6500000166 065G060310422K Y CAP CHIP 0603 100N 25V X7R +/-10% 1
C023 9JR6500000166 065G060310422K Y CAP CHIP 0603 100N 25V X7R +/-10% 1
C024 9JR6500000166 065G060310422K Y CAP CHIP 0603 100N 25V X7R +/-10% 1
CN016 9JR3300000037 033G8032 4F X WAFER 4P 1.25MM 1
R016 9JR6100000289 061G0603222 T RST CHIP 2K2 1/10W 5% 1
R017 9JR6100000289 061G0603222 T RST CHIP 2K2 1/10W 5% 1
R018 9JR6100000110 061T0603471 T RST CHIP 470R 1/10W 5% 1
R019 9JR6100000250 061T0603562 T RST CHIP 5K6 1/10W 5% 1
R021 9JR6100000110 061T0603471 T RST CHIP 470R 1/10W 5% 1
R022 9JR6100000250 061T0603562 T RST CHIP 5K6 1/10W 5% 1
SW016 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1
SW017 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1
SW018 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1
SW019 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1
SW020 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1
SW021 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1
SW022 9JR7700000003 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL 1

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
