Sharp LC-26S7E-BK User Manual

2008-03-14
LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
187
LC-19S7E-BK
No Parts code Sharp code Description Qty
1 705GZ934125 9JR7050000046 Bezel Assy 1
2 705GZ934128 9JR7050000049 Key PAD Assy 1
3 078G0030904 M 9JR7800000005 SPK BOX 2
4 750TVM185B1112N0SH 9JR7500000014 PANEL 1
5 705GZ915020 9JR7050000045 MAIN FRAME 1
6 PWTV9942LPR1 9JR9900000026 POWER BOARD 1
7 CBPF93KBP5 9JR9900000023 SCALER BOARD 1
8 IRPF9PB2 9JR9900000024 IR BOARD 1
9 KEPF9PA6 9JR9900000025 KEY BOARD 1
10 P34T0369PAA 1T0100 9JR3400000006 NECK 1
11 705GZ934126 9JR7050000047 BACK COVER ASSY 1
12 705GZ934127 9JR7050000048 BASE ASSY 1
13 P85T0113101 9JR8500000004 SHIELDING ATV 1

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
