Sharp LC-26S7E-BK User Manual

2008-03-14
LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
29
The sound is not emitted from the speaker though the picture has come out.
↓
No sound output in all modes?
TEREMINAL UNIT: ↓
↓YES
↓YES
↓YES
↓YES
↓YES
No sound (during the reception of TV(ANALOG) broadcasting)
↓
Does not the sound go out though the picture has come out when UHF/VHF is received?
TEREMINAL UNIT: ↓
↓YES
↓YES
No sound from external input devices (1)
Is the audio signal output of pin (84) (DACOUTL0) and pin (85)
(DACOUTR0) of IC U4201 normal?
NO
Check IC U4201 and its peripheral circuits.
Is audio signal input to pin (5)(LIN), pin (6)(RIN) of IC U6102
(AMP)?
NO
Check the line between IC U6101 and IC U6102.
Is MUTE/SHUTDOWN circuit [AMP_MUTE, AMP_STBY] normal?
Is the audio signal output of pin (3,4) (LOUT+) and pin (1,2)
(ROUT+) of CN6101 (AUDIO-CONNECTOR) normal?
NO
Check the AMP_MUTE and AMP_STBY. (Q6106, etc.)
NO
Check IC U6102 and its peripheral circuits.
Check Speaker Box (right and left) and wire harness.
Is the SIF signal output from pin (13) of TUNER (TU1101)?
Is the SIF signal sent to pin 54(SIFP) and pin 55(SIFM) of IC
U4201?
NO
Check the tuner and its peripheral circuits. Replace as required.
NO
Check IC U4201 its peripheral circuits.
.
Refer to “No sound output in all modes”.
Is the audio signal output of pin (9) (OUTL) and pin (11) (OUTR) of
IC U6101 normal?
NO
Check IC U6101 and its peripheral circuits.

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
