Sharp LC-26SB25E Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
144
Model: LC-26SB25E(CMO)
Item Code number Description Sharp C/N
Mechanical Parts
35 705TP833007 KEY PAD ASSY 9JR7050000011
30 705TP834023 BEZEL ASSY 9JR7050000012
40 705TP834024 REAR COVER ASSY 9JR7050000013
50 705TP837008 BASE ASSY 9JR7050000018
60 705TP837012 BASE STAND ASSY 9JR7050000022
110 P11T0020101 COVER _SERVICE 9JR1100000001
1185 078T 495902 2M Speaker 8ohm/6W 120mmX30mm 9JR7800000003
1186 078T 495902 2M Speaker 8ohm/6W 120mmX30mm 9JR7800000003
Accessory
135 705TZ841028 DFU ASSY 9JR7050000023
136 705TZ841031 DFU ASSY 9JR7050000024
144 P41TN025843 1C QSG-1 (Western & North Europe) 9JR4100000008
145 P41TN026843 1B QSG-2 (Eastern Europe & Russia) 9JR4100000009
1172 089T404A18NHT2 POWER CORD 1.8M 4L4L-040-00K 9JR8900000003
1176 098TRABD5NESHC REMOTE CONTROL RL57S 9JR9800000002
Packing
450 P44TE009843 1A CARTON 9JR4400000012
451 705TZ8CS007 CUSHION ASSY 9JR7050000026
miscellanea
96 0Q1T 930 8 47 CR3 SCREW 9JR0100000007
97 0M1T 940 16 47 CR3 SCREW M4X6 9JR0100000002
98 0Q1T 940 16 47 CR3 SCREW 9JR0100000020
99 0Q1T1040 8120 SCREW 9JR0100000010
100 0M1T1430 5120 SCREW TAPPING M3X5 9JR0100000018
101 0M1T1730 8106 CR3 SCREW 9JR0100000019
102 0M1T1140 6120 SCREW 4*6MM 9JR0100000003
103 0M1T 330 6 47 CR3 SCREW 9JR0100000001
106 0Q1T1830 12 47 CR3 SCREW_THW K30x12 PT W=8.5 9JR0100000022
107 0M1T 330 4120 SCREW 9JR0100000016
126 P40TEV0084316A RATING LABEL 9JR4000000025
127 P40TA00081328A FAMILY SHEET- SERVICE 9JR4000000004
130 P40TE00084334A CARTON LABEL 9JR4000000024
137 P40TE00084330B LABEL_SIDE_IO 9JR4000000023
143 P45T 48005 1A P.E. BAG(100 X 70) 9JR4500000003
455 P45T 46025 PE BAG(800X650-0.72mm) 9JR4500000007
8390 095T8014 4F928 HARNESS 4P-4P 490mm 75274 9JR9500000010
8391 095T8014 5F915 HARNESS 5P-5P 380mm 75273 9JR9500000013
8600 095T8013 2FA15 Harness 2P-FAST*2 440mm 76821 9JR9500000035
8601 095T8013 3FA07 Harness 3P-FAST*2 770mm 76822 9JR9500000036
8750 095T8018 40900 FP HARNESS 40P-FFC 230mm 75270 9JR9500000021
8902 095T801412FA15 Harness 12P-12P 115mm 76810 9JR9500000031
8903 095T801414F924 HARNESS 14P-13P 220mm 75271 9JR9500000019
LCD panel
1050 750TVM260B1111N000 PANEL V260B1-L11 26" CMO TW 9JR7500000002
1050 750TVM260B1113N000 PANEL V260B1-L11 NH CMO 9JR7500000006
PCB assy
1053 CBPF82MBPM Main Pcb Assy SHARP 26"-CMO 9JR9900000007
1054 ADTV82420PA3 POWER PCB ASSY 9JR9900000005
1056 IRPF8PB7 IR PCB ASSY 9JR9900000009
1057 KEPF8PB2 KEY BOARD 9JR9900000010
Main PCB
1053 CBPF82MBPM Main Pcb Assy SHARP 26"-CMO
1261 TUPF8PD4 TUNER+EEPROM ASSY 9JR9900000016
1262 705TP856111 NOR FLASH ASSY (U390) 9JR7050000035
