Sharp LC-26SB25E Service Manual

2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
151
C719 065T040210312K Y CAP CHIP 0402 10N 16V X7R +/-10% 9JR6500000011
C721 065T040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 9JR6500000014
C722 065T040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 9JR6500000014
C750 065T040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 9JR6500000014
C751 065T060310412K Y CAP CHIP 0603 0.1UF K 16V X7R 9JR6500000036
C752 067T 3114704ET EC SMD 47U 25V VGA 6.3x5.7mm 9JR6700000074
C753 065T060310512K 3 MLCC 0603 CAP 1uF K 16V X7R 9JR6500000043
C754 065T0805475A2K 3 CAP CHIP 4.7UF 10V X7R +/- 10% 9JR6500000092
C755 065T040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 9JR6500000014
C756 067T511F1013CT EC SMD 100U 16V MV 6.3x7.7mm 9JR6700000094
C757 065T060310512K 3 MLCC 0603 CAP 1uF K 16V X7R 9JR6500000043
C758 065T040210412K Y CAP CHIP 0402 100N 16V X7R +/-10% 9JR6500000014
CN100 033T380212B Y FP WAFER 2.0mm 12P 67032 9JR3300000029
CN390 033T3802 4 X CONNECTOR 9JR3300000020
CN391 033T3802 5 AUDIO IN 9JR3300000022
CN392 033T3802 3E FP WAFER 2.0MM 3P 63043 9JR3300000006
CN400 088T 500902 P PCMCIA CONN. CPC-BTRCVDB0-S02-H 9JR8800000027
CN500 088T 35521U ST SCART CONN. 21P V/T 2SC1504-000111 9JR8800000026
CN501 088T 35521U ST SCART CONN. 21P V/T 2SC1504-000111 9JR8800000026
CN552 088T 78 13A36 YG RCA JACK 1*3 G/BL/R V/A RCA-346D-02 9JR8800000019
CN553 088T 78 13A35 YG RCA JACK 1*3 W/R/B V/A RCA-346D-01 9JR8800000018
CN554 088T 35315F FX
D-SUB 15PIN FEMALE VERTICAL 附螺絲
9JR8800000025
CN555 088T 30252S PHONE JACK 3.5mm 3P V/A GREEN 9JR8800000022
CN556 088T 78 13A37 YG RCA JACK 1*2 W/R V/A RCA-276D-01 9JR8800000020
CN600 033T3802 2B Y FP WAFER 2.0mm 2P 67022 9JR3300000025
CN601 033T3802 3B Y FP WAFER 2.0mm 3P 67023 9JR3300000026
CN602 088T 302912 S PHONE JACK 3.5mm 7P BLACK 2SJ1508-001111 9JR8800000023
CN650 088T 78 13A39 YG S JACK + RCA JACK 1*3 Y/W/R RCA-333S-010 9JR8800000021
CN700 088T 340 19TNS HDMI HEADER 19P 5300-519-441-72 9JR8800000014
CN702 088T 340 19TNS HDMI HEADER 19P 5300-519-441-72 9JR8800000014
CN750 033T8033 40 FP CON. V 2*20P M 1.25 SM 60949 9JR3300000014
D100 093T 60S906 T DIODE 3A/40V SS3P4 DO-220AA 9JR9300000054
D101 093T 60S906 T DIODE 3A/40V SS3P4 DO-220AA 9JR9300000054
D390 093T 64S522SEM DIODE LL4148 SEMTECH 9JR9300000055
D391 093T 64 33 BAV99 SOT-23 9JR9300000044
D392 093T 64 33 BAV99 SOT-23 9JR9300000044
D500 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D501 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D502 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D503 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D504 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D505 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D506 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D507 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D508 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D509 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D510 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D511 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D512 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D553 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D554 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D555 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D556 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D557 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D560 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D561 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D562 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D563 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D564 093T 64S522SEM DIODE LL4148 SEMTECH 9JR9300000055
D565 093T 64S522SEM DIODE LL4148 SEMTECH 9JR9300000055
D566 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D567 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D568 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D569 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D570 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D571 093T 64S900 T DIODE BAS316 SOT-323 PHILIPS 9JR9300000030
D600 093T 64S522SEM DIODE LL4148 SEMTECH 9JR9300000055
