Sharp LC-26SB25E Service Manual

2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
153
L300 073T 63828 T CHIP INDUCROR 0U82 10% MLF1608DR82K 9JR7300000007
L500 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L501 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L502 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L503 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L504 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L505 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L550 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L551 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L552 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L554 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L556 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L558 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L561 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L562 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L563 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L564 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L565 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L650 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L652 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L653 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L654 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L655 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L656 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L657 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L700 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
L701 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002
Q100 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q101 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q103 057T 763900 FET SI3441BDV TSOP-6 9JR5700000020
Q104 057T 7631PH SI5441DC 1206-8 9JR5700000019
Q106 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q108 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q109 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q150 057T 7631PH SI5441DC 1206-8 9JR5700000019
Q151 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q200 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q201 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q202 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q203 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q301 057T 417511 TRA MMBT3904 BLUE ROKET 9JR5700000025
Q400 057T 763 50 FET ME2301 -2.8A/-20V SOT-23 9JR5700000036
Q401 057T 417 12 T TRA 2N3904S-RTK/PS SOT-23 KEC 9JR5700000024
Q500 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q550 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q600 057T 477904 T TRA BC847BW 100mA/45V SOT-323 9JR5700000012
Q601 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q606 057T 761902 T TRA BC857BW 100mA/50V SOT-323 9JR5700000018
Q607 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q608 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q609 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q610 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q611 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q612 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q613 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q614 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q615 057T 761902 T TRA BC857BW 100mA/50V SOT-323 9JR5700000018
Q616 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q700 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q702 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q705 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q706 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q750 057T 417511 TRA MMBT3904 BLUE ROKET 9JR5700000025
Q751 057T 417511 TRA MMBT3904 BLUE ROKET 9JR5700000025
R100 061T0603223 Y RST CHIPR 22KOHM +-5% 1/10W YAGEO 9JR6100000095
R101 061T0603223 Y RST CHIPR 22KOHM +-5% 1/10W YAGEO 9JR6100000095
R102 061T0603512 Y RST CHIPR 5.1KOHM +-5% 1/10W YAGEO 9JR6100000119
