Sharp LC-26SH7E/RU

LC-19SH7E/RU, LC-26SH7E/RU, LC-32SH7E/RU, LC-42SH7E/RU
173
CHAPTER 9. PARTS GUIDE
[1] SPARE PARTS LIST
Model: LC-19SH7E_BK(CMO)
Item TPV Code Number SHARP Code Number Description Quantity
30 705GZ934122 9JR7050000059 BEZEL ASSY 1
36 A33T0551PAAA1T0100 9JR3300000046 KEY COVER 1
37 A33T0550PAA 1T0100 9JR3300000047 KEY PAD 1
38 0Q1T3130 6120 9JR0100000033 SCREW 2
40 705GZ934123 9JR7050000060 REAR COVER ASSY 1
50 705GZ934124 9JR7050000061 STAND ASSY 1
90 P34T0369PAA 1T0100 9JR3400000006 NECK 1
93 0M1T1730 8106 CR3 9JR0100000019 SCREW 1
94 P01T0006 1 9JR0100000028 SCREW (PH+W6#x15 HI-LO W=13) 4
95 0Q1T 940 12 47 CR3 9JR0100000008 T4X12 SCREW 4
96 0M1G1740 8 47 CR3 9JR0100000026 SCREW FOR GROUND 42-D000649 4
97 0M1T1430 8 47 CR3 9JR0100000027 Screw PHW M3-0.5x8 TPS Zi/BL 2
98 0G1T1030 10 47 CR3 9JR0100000024 PAN HEAD WITH WASHER 5
99 0M1G 330 6 47 CR3 9JR0100000025 SCREW 42-D005390 1
100 N02T6008 1 9JR0200000001 SCREW 2
126 P40G 190843 1C 9JR4000000050 RATING LABEL 1
127 P40TA00081328A 9JR4000000041 FAMILY SHEET- SERVICE 1
130 P40G0001843 9A 9JR4000000041 CARTON LABEL 1
131 P40TN00084357A 9JR4000000022 ITALIAN CAUTION LABEL 1
302 0M1T1730 8106 CR3 9JR0100000019 SCREW 9
304 P11G0023101 9JR1100000002 Wire Saddle Clip (CH-01U) 4
449 705GZ941053 9JR7050000093 Carton Assy 1
451 P44G9020101 9JR4400000026 CUSHION_T 1
452 P44G9020201 9JR4400000027 CUSHION_B 1
453 P45G 46026 9JR4500000010 PE BAG(560X450-0.72mm) 1
504 P40TD000813 9A 9JR4000000005 family sheet 1
1050 750TVM185B1112N0SP 9JR7500000018 PANEL M185B1-L01 NB CMO 1
1172 089G204A15NLS1 9JR8900000009 POWER CORD 1.5M PE8C5Z1B90A-04B 1
1176 098GRABD1NESPJ 9JR9800000003 REMOTE CONTROL RC-GJ2100B-H FOR SHARP 1
1185 078G0030903 M 9JR7800000007 Speaker + wire assembly 8ohm 3w 100X30mm 1
8391 095G8014 9F901 9JR9500000052 HARNESS 9P-5+3P 180+290mm 75360-HF 1
8751 089G179E30N916 9JR8900000010 FFC CABLE 30P 310mm P1.0 117201-30532 1
135 705GZ941047 9JR7050000062 DFU ASSY(Western Europe)(Eastern Europe) 1
136 705GZ941048 9JR7050000063 DFU ASSY(North Europe) 1
1054 PWTV9942LPR1 9JR9900000026 POWER PCB ASSY 1
BD901 093G 50460913 9JR9300000059 BRIDGE DIODE TS4B06G 4A/800V 1
C801 065G 3J5606ET 9JR6500000167 CAP CER 56PF J 3KV 1
C802 065G 3J5606ET 9JR6500000167 CAP CER 56PF J 3KV 1
C803 065G080510432K Y 9JR6500000168 CAP CHIP 0805 100N 50V X7R +/-10% 1
C804 065G080547332K Y 9JR6500000169 CAP CHIP 0805 47N 50V X7R +/-10% 1
C805 067G 215471 6K 9JR6700000102 EC 470uF 35V ED 12.5x16mm 1
C806 065G080510522K Y 9JR6500000170 CAP CHIP 0805 1UF K 25V X7R 1
C807 065G 3J2706ET 9JR6500000171 27PFJ 3KV SL 1
C808 065G080547332K Y 9JR6500000169 CAP CHIP 0805 47N 50V X7R +/-10% 1
C809 065G080510522K Y 9JR6500000170 CAP CHIP 0805 1UF K 25V X7R 1
C810 065G 3J5606ET 9JR6500000167 CAP CER 56PF J 3KV 1
C811 065G 6J2096ET 9JR6500000175 2PF 5% SL 6KV 1
C812 065G 3J5606ET 9JR6500000167 CAP CER 56PF J 3KV 1
C813 065G060322131J Y 9JR6500000177 CAP CHIP 0603 220P 50V NPO +/-5% 1
C816 065G080539131J Y 9JR6500000178 CAP CHIP 0805 390P 50V NPO +/-5% 1
C817 065G080547332K Y 9JR6500000169 CAP CHIP 0805 47N 50V X7R +/-10% 1
C818 065G080533332K Y 9JR6500000180 CAP CHIP 0805 33N 50V X7R +/-10% 1
C819 065G080510522K Y 9JR6500000170 CAP CHIP 0805 1UF K 25V X7R 1
C820 065G080533332K Y 9JR6500000180 CAP CHIP 0805 33N 50V X7R +/-10% 1
C821 065G080510522K Y 9JR6500000170 CAP CHIP 0805 1UF K 25V X7R 1
C822 065G080510422K Y 9JR6500000184 CAP CHIP 0805 100N 25V X7R +/-10% 1
C826 065G 3J2706ET 9JR6500000171 27PFJ 3KV SL 1
