Sharp LC-26SH7E/RU

2008-03-14
LC-19SH7E/RU, LC-26SH7E/RU, LC-32SH7E/RU, LC-42SH7E/RU
41
Reading with Minolta CA-210.
Note:
1. Use Minolta CA-210 for color coordinates and luminance check.
2. Befor checking,all colour analyzers (CA-210) should be coordinates with a same reference TV set.
3. Check the luminance in the center of the screen with 100% White when Brightness control at 100; Contrast control at 100
Luminance > 230 cd/m
2
<< For 19” only at color temp.- warm mode >>
> 350 cd/m
2
<< For 26” only at color temp.- cool mode >>
> 400 cd/m
2
<< Foolor temp.- cool mode >>
3. Factory mode preset.
Default Values
VIRGIN_MODE On
GAMMA_TABLE
COLOR_ENHANCE On
Note: VIRGIN_MODE is ON for outging and is Off at production line.
YPbPr PC
ADC_GAIN_R 64 64
ADC_GAIN_G 64 64
ADC_GAIN_B 64 64
ADC_OFFSET_R 128 128
ADC_OFFSET_G 128 128
ADC_OFFSET_B 128 128
Note: These above values will be changed after doing “AUTO_COLOR” at FAC mode menu.
PC
NORMAL COOL WARM
CLR_TEMP_R 0 0 0
CLR_TEMP_G 0 0 0
CLR_TEMP_B 0 0 0
Note: These above values will be changed after doing W/D alignment at FAC mode menu
TUNER_ID 4 (Panasonic ENG37E14KRF)
PANEL_ID 110: for CMO 19” panel 122: for CMO 26” panel 33: for Sharp 32” panel
These above values are defined by Development Division and written in release NVM.
Picture Mode x y
Normal (9000
o
K) 0.289±0.015 0.291±0.015
Cool (12000
o
K) 0.272±0.010 0.277±0.010
Warm (6500
o
K) 0.314±0.015 0.319±0.015
