2008-03-14
LC-19SH7E/RU, LC-26SH7E/RU, LC-32SH7E/RU, LC-42SH7E/RU
7
Preparation
Mount the TV Stand
1. Put the TV face down on a safe surface
that is covered by a soft and smooth cloth.
2. Adjust the TV stand to the bottom of the TV.
3. Fasten the screws by using a cross-head screwdriver. (Not supplied).
NOTE:
To detach the TV stand, perform the steps in reverse order.
Wall mounting
TV screen size
( inches)
VESA-compatible wall bracket
(millimeters) (W x H)
Screw type
19” 100 x 100 mm Metric 4 x 10 mm
26” 200 x 100 mm Metric 4 x 10 mm
32” 200 x 200 mm Metric 6 x 10 mm
42” 400 x 200 mm Metric 6 x 10 mm
.
To Next Page
