LC32D44E/S/RU-BK/GY (1st Eddition)
5 – 7
22 AIN2 I N.C.
23 AIN3 I N.C.
24 AC_DET I Power supply detection.
25 ANT_ERR I ANT5V short detection.
26 BL_ERR I Backlight detection.
27 SV1JSW I S-terminal detection.
28 QS_EN O Panel controller QS.
29 FRAME O 50/60Hz select.
30 T1 I Panel controller TEMP.
31 T2 I Panel controller TEMP.
32 T3 I Panel controller TEMP.
33 BANK_SEL O Panel controller
34 R/L O Panel controller. Flip horizontal.
35 U/D O Panel controller. Flip vertical.
36 EXT_DTV O DTV_etc. select (H,V,Audio)
37 HDMI_PC O HDMI-PC select (H,V,Audio)
38 SCART12 O SCARTselect.
39 PE O Panel enable.
40 HP_MUTE O Mute. Headphono.
41 ANT+5V_SW O ANT+5V control
42 DTN_BUS_SEL O D-TUNER I2C select
43 DTM_RST O DTV PWB reset
44 TCON_WP O Counter adjustment write-protect
45 LVDS_EN O N.C
46 CONT_DET --- N.C
47 PS_ON O Power_on.
48 PCON1 O DC-DC_on.
49 TEST O N.C
50 LCD_POW O N.C
51 12V_DET O LCD_12V detection.
52 SCL I I2C Slave clock
53 SDA I/O I2C Slave data
54 I-REQ O Sub-microprocessor interrupt
55 SCL_F I N.C. (Pull-up)
56 SDA_F I/O N.C. (Pull-up)
57 LEDPOW_R O Power R_LED ON.
58 LEDPOW_G O Power G_LED ON.
59 LEDSLP O N.C.
60 LEDOPC O N.C.
61 MUTE_SP O Mute.
62 S_MUTE O Mute.
63 S2_MUTE O Mute SCART2.
64 IREM_SW O N.C.
Pin No. Pin Name I/O Pin Function
