LC32D44E/S/RU-BK/GY (1st Eddition)
5 – 1
LC32D44E-BK
Service Manual
CHAPTER 5. MAJOR IC INFORMATIONS
[1] MAJOR IC INFORMATIONS
1. IC207 (RH-iXB964WJZZQ)
The STv0362 is a single-chip demodulator using COFDM (coded orthogonal frequency division Multiplexing) and is intended for digital terrestrial
receivers using compressed video, sound and data services. It converts IF or base band differential signals to MPEG-2 format by processing OFDM
carriers.
The STv0362 is fully compliant with the DVB-T specification (ETS 300 744) and Nor Dig Unified specification.
Pin No. Pin Name I/O Pin Function
Clock and resets
32 NOT_RESET I Hardware reset, active low
15 XTAL_I I Analog Crystal oscillator input/external clock (2.5 V)
14 XTAL_O O Analog Crystal oscillator output
13 VDDA_2V5 --- Supply Analog oscillator supply (2.5 V)
16 VDDA_2V5 --- Supply Analog PLL supply (2.5 V)
Analog interface
1 RF_LEVEL --- ADC 8 input for RF level monitoring
2 VDDA_2V5 --- Analog ADC 8 supply (2.5 V)
3 QP --- Positive Q analog input for baseband configuration
4 QM --- Negative Q analog input for baseband configuration
5 VDDA_ISO --- Analog ISO nwell polarization (2.5 V)
6 VDDA_2V5 --- Analog ADC 12 supply (2.5 V)
7 REFP --- Internal positive reference
8 REFM --- Internal negative reference
9 INCM --- Internal common mode
10 IM --- Negative I analog input for IF and baseband configuration
11 IP --- Positive I analog input for IF and baseband configuration
12 VDDA_1.0 --- Analog supply (1.0 V)
I2C interface
29 SDA I/O Serial data (open drain)
30 SCL I Serial clock (open drain)
21 SDAT I/O SDA tuner (open drain)
20 SCLT I SCL tuner
MPEG interface
43 D7 O Serial MPEG data or parallel MPEG data (bit 7)
42 D6 O Parallel MPEG data (bit 6)
40 D5 O Parallel MPEG data (bit 5)
39 D4 O Parallel MPEG data (bit 4)
37 D3 O Parallel MPEG data (bit 3)
36 D2 O Parallel MPEG data (bit 2)
35 D1 O Parallel MPEG data (bit 1)
33 D0 O Parallel MPEG data (bit 0)
44 CLK_OUT O MPEG byte or bit clock
46 STR_OUT O MPEG first byte sync
47 D/NOT_P O MPEG data valid/parity
48 ERROR O MPEG packet error
Front end controls
18 AGC_RF I/O RF AGC control (5 V tolerant)
17 AGC_IF I/O
IF AGC control (5 V tolerant)
64 TEST I/O Reserved test mode, must be grounded.
27 GPIO0 I/O General-purpose input/output port 0. Reserved test mode, must be grounded.
49 GPIO1 I/O General-purpose input/output port 1
60 GPIO2 I/O General-purpose input/output port 2 or lock indicator
59 GPIO3 I/O General-purpose input/output port 3 or lock indicator
58 GPIO4 I/O General-purpose input/output port 4
57 GPIO5 I/O General-purpose input/output port 5
54 GPIO6 I/O General-purpose input/output port 6
53 GPIO7 I/O General-purpose input/output port 7
52 GPIO8 I/O General-purpose input/output port 8. Reserved test mode, must be grounded.
61 GPIO9 I/O General-purpose input/output port 9
23 AUX_CLK I/O Auxiliary clock
25 CS0 I Chip select LSB
To Next Page
