LC32D44E/S/RU-BK/GY (1st Eddition)
5 – 11
115 PCS5 O TP3045
116 PCS4 O TP3043
117 PCS3 O TP3044
118 PCS2 O TP3034
119 PCS1 O TP3033
120 PCS0 O TP3032
121 PCLK2 O TP3022
122 PCLK1 O TP3031
123 GND1.8DIG --- Ground Digital Core
124 VSUP1.8DIG --- Supply Voltage Digital Core, 1.8 V.
125 LVDSA_4P O TP3030
126 LVDSA_4N O TP3029
127 VSUP3.3LVDS --- Supply Digital Voltage LVDS2 Port, 3.3 V.
128 LVDSA_3P O LVDS Channel 1 bit 3 Positive Output.
129 LVDSA_3N O LVDS Channel 1 bit 3 Negative Output.
130 GND3.3LVDS --- Ground Digital LVDS2, 3.3 V.
131 LVDSA_CLKP O LVDS Channel 1 Clock Positive Output.
132 LVDSA_CLKN O LVDS Channel 1 Clock Negative Output.
133 VSUP3.3LVDS --- Supply Digital Voltage LVDS2, 3.3 V.
134 LVDSA_2P O LVDS Channel 1 bit 2 Positive Output.
135 LVDSA_2N O LVDS Channel 1 bit 2 Negative Output.
136 GND3.3LVDS --- Ground Digital LVDS2, 3.3 V.
137 LVDSA_1P O LVDS Channel 1 bit 1 Positive Output.
138 LVDSA_1N O LVDS Channel 1 bit 1 Negative Output.
139 VSUP3.3LVDS --- Supply Digital Voltage LVDS2, 3.3 V.
140 LVDSA_0P O LVDS Channel 1 bit 0 Positive Output.
141 LVDSA_0N O LVDS Channel 1 bit 0 Negative Output.
142 VSUP1.8LVDS --- Supply Analog Voltage LVDS2, 1.8 V.
143 REXT O LVDS External Resistor 2.
144 GND1.8LVDS --- Ground Analog LVDS2, 1.8 V.
145 LVDSB_3P O TP3028
146 LVDSB_3N O TP3027
147 GND3.3LVDS --- Ground Digital LVDS2, 3.3 V.
148 LVDSBCLKP O TP3026
149 LVDSBCLKN O TP3025
150 VSUP3.3LVDS --- Supply Digital Voltage LVDS2, 3.3 V.
151 LVDSB_2P O TP3024
152 LVDSB_2N O TP3023
153 GND3.3LVDS --- Ground Digital LVDS2, 3.3 V.
154 LVDSB_1P O TP3013
155 LVDSB_1N O TP3012
156 VSUP3.3LVDS --- Supply Digital Voltage LVDS2, 3.3 V.
157 LVDSB_0P O TP3010
158 LVDSB_0N O TP3011
159 CADC4 I IF AGC For AGC adjustment.
160 CADC3 I SLOWSW_1I SLOW SW1 input.
161 CADC2 I SLOWSW_2I SLOW SW2 input.
162 CADC1 I TP3009
163 GND3.3DAC --- Ground DAC.
164 VSUP3.3DAC --- Supply Voltage DAC, 3.3V.
165 PWM3 O ST_RS
166 PWM2 O BL_ON Back-light on.
167 PWM1 O OFL1 Modulated light signal.
168 REV O TP3005
169 VSUP1.8FE --- Supply Voltage Analog Video Frontend, 1.8 V.
170 VSUP3.3FE --- Supply Voltage Analog Video Frontend, 3.3 V.
171 DHS I Digital Video H-Sync Input.
172 VIN21 I Analog Video 21 B HD Input.
173 VIN20 I Analog Video 20 G HD Input.
174 VIN19 I Analog Video 19 R HD Input.
175 VIN18 I Analog Video 18 Fast Blank 2 Input.
176 VIN17 I Analog Video 17 B HD Input.
177 VIN16 I Analog Video 16 G HD Input.
178 VIN15 I Analog Video 15 R HD Input.
Pin No. Pin Name I/O Pin Function
