LC32D44E/S/RU-BK/GY (1st Eddition)
5 – 14
201 LMIDATA15 I/O Bidirectional data.
199 LMIDATA14 I/O
198 LMIDATA13 I/O
197 LMIDATA12 I/O
194 LMIDATA11 I/O
192 LMIDATA10 I/O
191 LMIDATA9 I/O
190 LMIDATA8 I/O
180 LMIDATA7 I/O
178 LMIDATA6 I/O
175 LMIDATA5 I/O
174 LMIDATA4 I/O
171 LMIDATA3 I/O Bidirectional data.
169 LMIDATA2 I/O
168 LMIDATA1 I/O
167 LMIDATA0 I/O
208 LMIADDR12 O Address.
209 LMIADDR11 O
157 LMIADDR10 O
210 LMIADDR9 O
211 LMIADDR8 O
213 LMIADDR7 O
214 LMIADDR6 O
215 LMIADDR5 O
216 LMIADDR4 O
150 LMIADDR3 O
152 LMIADDR2 O
153 LMIADDR1 O
154 LMIADDR0 O
159 LMIBA1 O Bank select.
160 LMIBA0 O
182 LMIDQM0 O Data I/O mask lower.
186 LMIDQM1 O Data I/O mask upper.
181 LMIDQS0 O Data strobe lower.
188 LMIDQS1 O Data strobe upper.
162 NOT_LMICS O Chip select.
163 NOT_LMIRAS O Latch row address strobe.
164 NOT_LMICAS O Latch column address strobe.
206 LMICLKEN O Clock enable.
203 LMICLK O Clock.
202 NOT_LMICLK O Inverted clock.
183 LMI_VREF I Input reference voltage.
166 LMIRDNOTWR O Write enable signal.
Analog audio DAC pins
28 OUTLMINUS O Audio DAC left differential current output.
24 OUTRMINUS O Audio DAC right differential current output.
29 OUTLPLUS O Audio DAC left differential current output.
25 OUTRPLUS O Audio DAC right differential current output.
23 VGBOUT O Audio DAC filtered output reference voltage.
26 IREFADAC I Current reference for Audio DAC.
Digital audio pins
37 S/PDIF O Digital audio.
Analog video DAC pins
15 VDAC1OUT O Video DAC outputs.
16 VDAC2OUT O
17 VDAC3OUT O
18 VDAC4OUT O
14 GNDREXTVDAC I Video DAC external resistor ground.
13 REXTVDACRGB I VDAC external resistor input.
Transport stream pins
35 TS0INBITCLK I TSIN0 Parallel//Serial in.
33 TS0INBITCLKVALI
D
I
34 TS0INPACKETCLK I
36 TS0INDATA7 I
Pin No. Pin Name I/O Pin Function
