LC-32D62U/LC-37D62U 1st
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACEMENT ITEM)
N DUNTKD909FM02 - - R/C, LED Unit
N DUNTKD910FM02 - - KEY Unit
N DUNTKD999FM07 - N - TERMINAL Unit
[2] PRINTED WIRING BOARD ASSEMBLY
N DUNTKE028FM06 N MAIN Unit
!
N RDENCA203WJQZ POWER Unit
N CPWBX3520TPZC LCD CONTROL Unit
N RUNTKA283WJZZ INVERTER-A Unit [LC32D62U]
N RUNTKA275WJZZ INVERTER-A Unit [LC37D62U]
N RUNTKA284WJZZ INVERTER-B Unit [LC32D62U]
N RUNTKA276WJZZ INVERTER-B Unit [LC37D62U]
[3] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
N R1LK315D3LZ10Z N J 32" Wide LCD Panel Module Unit [LC32D62U]
N R1LK370D3LZ20Z N J 37" Wide LCD Panel Module Unit [LC37D62U]
[4] DUNTKD909FM02 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor, 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor, 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C107 VCEASY1CN107MY AC J Capacitor, 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Zener Diode, 12V
D103 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
D114 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
D115 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
IC101 VHITPS850++-1Y AG J IC, TPS850
P101 QPLGNA333WJZZY AD J Plug, 13pin (RA)
Q102 VS2SC3928AR-1Y AB J Transistor, 2SC3928A
Q106 VS2SC3928AR-1Y AB J Transistor, 2SC3928A
Q107 VS2SC3928AR-1Y AB J Transistor, 2SC3928A
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor, 27k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor, 10k x2 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor, 10k x2 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
SLD101 PSLDM4646CEFW AD J Shield Case
[5] DUNTKD910FM02 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode, 15V
D152 RH-EX0646GEZZY AA J Zener Diode, 15V
D155 RH-EX0646GEZZY AA J Zener Diode, 15V
P151 QPLGNA058WJZZ AC J Plug, 4pin (KM)
R151 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch, CH-UP
S152 QSW-K0003AJZZ+ AB J Switch, CH-DOWN
S153 QSW-K0003AJZZ+ AB J Switch, INPUT
S154 QSW-K0003AJZZ+ AB J Switch, VOL-UP
S155 QSW-K0003AJZZ+ AB J Switch, VOL-DOWN
S157 QSW-K0003AJZZ+ AB J Switch, POWER
[6] DUNTKD999FM07 (TERMINAL Unit)
C501 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C502 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C503 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C504 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C505 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C506 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C507 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C508 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C509 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C510 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C511 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C512 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C513 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C514 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C515 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C516 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C517 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C518 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C519 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C520 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C521 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C522 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C523 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C524 VCAAPF1CJ396MY AF J Capacitor, 39 16V Electrolytic
C525 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
