LC-32D62U/LC-37D62U 1st
5 – 7
8 [FR DDRTEST]
1 DDRA TEST1
2 DDRA TEST2
3 DDRB TEST1
4 DDRB TEST2
5 DDRB TEST3
9 [M GAMMA IN]
1 MONITOR GAMMA IN 1 Standard value 1(WBI10184) Adjustment gradation setting.
2 MONITOR GAMMA IN 2 Standard value 2(WBI20352)
3 MONITOR GAMMA IN 3 Standard value 3(WBI30528)
4 MONITOR GAMMA IN 4 Standard value 4(WBI40656)
5 MONITOR GAMMA IN 5 Standard value 5(WBI50800)
6 MONITOR GAMMA IN 6 Standard value 6(WBI60928)
7 GAMMA WRITE WB adjustment data writing
8 GAMMA RESET WB adjustment data reading
10 [M GAMMA R1]
1 MONITOR GAMMA R 1 WB adjustment Point 1, R adjustment value Parameter for six-point adjustment
2 MONITOR GAMMA G 1 WB adjustment Point 1, G adjustment value
3 MONITOR GAMMA B 1 WB adjustment Point 1, B adjustment value
4 MONITOR GAMMA R 2 WB adjustment Point 2, R adjustment value
5 MONITOR GAMMA G 2 WB adjustment Point 2, G adjustment value
6 MONITOR GAMMA B 2 WB adjustment Point 2, B adjustment value
7 MONITOR GAMMA R 3 WB adjustment Point 3, R adjustment value
8 MONITOR GAMMA G 3 WB adjustment Point 3, G adjustment value
9 MONITOR GAMMA B 3 WB adjustment Point 3, B adjustment value
10 GAMMA WRITE WB adjustment data writing
11 GAMMA RESET WB adjustment data reading
11 [M GAMMA R4]
1 MONITOR GAMMA R 4 WB adjustment Point 4, R adjustment value Parameter for six-point adjustment
2 MONITOR GAMMA G 4 WB adjustment Point 4, G adjustment value
3 MONITOR GAMMA B 4 WB adjustment Point 4, B adjustment value
4 MONITOR GAMMA R 5 WB adjustment Point 5, R adjustment value
5 MONITOR GAMMA G 5 WB adjustment Point 5, G adjustment value
6 MONITOR GAMMA B 5 WB adjustment Point 5, B adjustment value
7 MONITOR GAMMA R 6 WB adjustment Point 6, R adjustment value
8 MONITOR GAMMA G 6 WB adjustment Point 6, G adjustment value
9 MONITOR GAMMA B 6 WB adjustment Point 6, B adjustment value
10 GAMMA WRITE WB adjustment data writing
11 GAMMA RESET WB adjustment data reading
12 [SOUND 1]
1 AUDIO SWITCH
2 FORCED FLAT MODE
3 AIN1_ADC_VOLUME
4 AIN2_ADC_VOLUME
5 AIN3_ADC_VOLUME
6 AIN4_ADC_VOLUME
7 AIN5_ADC_VOLUME
8 AIN6_ADC_VOLUME
13 [SOUND 2]
1 INPUT_MIXER_GAIN_SP
2 INPUT_MIXER_GAIN_HP
3 INPUT_MIXER_GAIN_EXT
4 INPUT_MIXER_GAIN_EXT_HP
5 OUTPUT_MIXER_GAIN
6SUB_VOLUME_FLAT
7 SUB_VOLUME_EQ
8 SUB_VOLUME_AUDYSSEY
Page Line Item Description Remarks (adjustment detail, etc.)
To Next Page
