Sharp LC-32D65E Service Manual

LC-32D65E/RU, LC-37D65E/RU
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[6] CABINET PARTS (LC-32D65E/RU)
1 CCABAC094WJ01 BE N S Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 HDECQA992WJ1A AE N S LED Decoration
1-3 HDECSA038WJ1A AH N S Shine Trim
1-4 HPNLSA195WJ1A AM N S SP Sheet
1-5 PSPAHB358WJZZ AC N S Mask Himelon (Bottom)
2 CCABBB333WJ01 BE N S Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HiNDPC866WJSA AN N S Terminal Label
2-3 LHLDZA929WJZZ AD N S VESA Holder, x4
2-4 XEBS930P08000 AA J Screw, x4 (VESA Holder)
3 CCOVAC892WJ01 AN N S Control Cover Ass'y
3-1 Not Available - N - Control Cover
3-2 HiNDPC867WJSA AE N S Control Label
3-3 HiNDPC919WJSA AE N S SIDE AV Label
4 CDAi-A482WJ02 BC N S Stand Unit
5 GCOVAC893WJ1A AM N S Bottom Cover
6 LANGKB597WJFW AM N S Panel Support Angle, x2
7 LANGKB598WJFW AN N S Stand Angle
9 LHLDWA048WJKZ AB J Wire Holder (SP Wire)
10 LHLDWA143WJKZ AC J Wire Holder (Cable), x4
11 LHLDZA934WJKZ AB N J POWER PWB Holder, x3
12 LHLDZB147WJKZ AD N S LCD Holder A, x2
13 LHLDZB148WJKZ AD N S LCD Holder B, x2
14 NSFTZA237WJFN AC J Screw, x4 (D-SUB)
15 PSLDMB475WJFW AP N S Full Shield
16 PSPAZB745WJKZ AF J Spacer (30*25*t2.5)
17 PSPAZB864WJKZ AG J Spacer (24*12*t5.0)
18 QCNW-H326WJQZ AG N S Connecting Cord (RA)
19 QCNW-H330WJQZ AG N S Connecting Cord (LB)
20 QCNW-H334WJQZ AH N S Connecting Cord (PD)
21 QCNW-H343WJQZ AF N S Connecting Cord (SP)
22 QCNW-H588WJQZ AX N S Connecting Cord (LW)
23 QCNW-H589WJQZ AG N S
Connecting Cord (LP)
24 RSP-ZA351WJZZ AR N S Speaker (L)
25 RSP-ZA352WJZZ AR N S Speaker (R)
26 XBBS730P04000 AA J Screw (TUNER/SHIELD)
27 XBPS830P06000 AA J Screw, x3 (HDMI)
28 XEBS930P08000 AA J Screw (21pin)
29 XEBS940P16000 AB J Screw, x10 (CAB-B FIX)
30 XEBSN40P10000 AB J Screw, x4 (LCD-HOLDER FIX)
31 XHPS730P06WS0 AA J Screw, x32 (ANG/PWB)
32 XHPS730P10WS0 AA N S Screw (MAIN PWB)
33 TLABZB982WJZZ AH N S POP Label (LC-32D65E)
33 TLABZB983WJZZ AH N S POP Label (LC-32D65RU)
34 TLABNC117WJZZ AC N S Model Label
