LC-32D65E/RU, LC-37D65E/RU
2 – 4
9. Remove the 1 lock screw and detach the Bottom Cover.
10.Remove the 2 lock screws 4 lock screws and detach the Stand Angle.
11.Remove the LED Unit.
1
2
3
LED Unit
Stand Angle
3
2
Bottom Cover
1
