Sharp LC-32D65E Service Manual

LC-32D65E/RU, LC-37D65E/RU
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLY (LC-32D65E/RU)
N DUNTKE685FM01 CQ N R MAIN Unit
N DUNTKE687FM01 BB N R LED Unit
N RUNTKA456WJQZ BS N S POWER/INVERTER Unit (Unit Replacement Item)
[2] PRINTED WIRING BOARD ASSEMBLY (LC-37D65E/RU)
N DUNTKE685FM03 CQ N R MAIN Unit
N DUNTKE687FM03 BB N R LED Unit
N RDENCA267WJQZ BL N S POWER Unit (Unit Replacement Item)
N RUNTKA457WJQZ BK N S INVERTER Unit (Unit Replacement Item)
[3] LCD PANEL
N R1LK315D3LW1AY N J 32" LCD Panel Module
N R1LK370D3LW1AY N J 37" LCD Panel Module
[4] DUNTKE685FM01/FM03 (MAIN Unit)
C501 VCERMZ1CN107MY AD J Capacitor 100 16V Electrolytic
C502 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C503 VCERMZ1CN477MY AE J Capacitor 470 16V Electrolytic
C504 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C505 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C506 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C507 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C511 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C512 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C513 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C514 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C515 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C516 VCERMZ1CN477MY AE J Capacitor 470 16V Electrolytic
C517 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C518 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C519 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C524 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C525 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C528 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C529 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C530 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C532 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C533 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C534 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C535 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C538 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C539 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C540 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C541 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C542 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C543 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C544 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C545 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C546 VCKYCZ1HB102KY AB J
Capacitor 1000p 50V Ceramic
C547 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C548 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C549 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C550 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C551 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C552 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C553 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C556 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C557 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C558 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C560 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C561 VCERMZ1CN107MY AD J Capacitor 100 16V Electrolytic
C562 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C563 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C565 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C566 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C567 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C568 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C572 VCERML1CN226MY AC J Capacitor 22 16V Electrolytic
C573 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C574 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C575 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C576 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C577 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C578 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C579 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C580 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C581 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C582 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C583
VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C584 RC-KZA154WJZZY AB J Capacitor 4.7 16V Ceramic
C585 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
