LC-32D65E/RU, LC-37D65E/RU
2 – 11
13.Remove the 6 lock screws , and detach the Panel Support Angle.
14.Remove the 6 lock screws , 4 hooks and detach the LCD Panel Module.
1
2
Panel Support Angle
2
2
Hook
Hook
Hook
Hook
LCD Panel Module
Hook
1
1
