LC-32D65E/RU, LC-37D65E/RU
3 – 4
8/16 1 ANALOG PC ADJ Enter DVI ANALOG video level adjustment
2 R OFFSET 64 R CUTOFF adjustment value
3 G OFFSET 64 G CUTOFF adjustment value
4 B OFFSET 66 B CUTOFF adjustment value
5 R GAIN 193 R DRIVE adjustment value
6 G GAIN 189 G DRIVE adjustment value
7 B GAIN 194 B DRIVE adjustment value
9/16 1 SCART RGB ADJ Enter SCART RGB level adjustment
2 SCART R CUTOFF 65 SCART R CUTOFF adjustment value
3 SCART G CUTOFF 60 SCART G CUTOFF adjustment value
4 SCART B CUTOFF 64 SCART B CUTOFF adjustment value
5 SCART R GAIN 200 SCART R GAIN adjustment value
6 SCART G GAIN 195 SCART G GAIN adjustment value
7 SCART B GAIN 201 SCART B GAIN adjustment value
10/16 1 VCOM ADJ 69
2 LCD LUMA ADJ Enter
3 LCD LUMA UP 26
4 LCD LUMA DOWN 13
11/16 1 DDRA TEST1 Enter
2 DDRA TEST2 Enter
3 DDRB TEST1 Enter
4 DDRB TEST2 Enter
5 DDRB TEST3 Enter
6 FRC ON/OFF Enter
7 SOUSAM DDR BIST Enter
8 SOUSAS DDR BIST Enter
12/16 1 R GAIN(LO) 0
2 G GAIN(LO) 0
3 B GAIN(LO) 0
4 R GAIN(HI) 0
5 G GAIN(HI) 0
6 B GAIN(HI) 0
13/16 1 MONITOR TIME OUT ON
2 MONITOR MAX TEMP 30
3 MONITOR EEP READ/WRITE WRITE
4 MONITOR EEP ADR 0x 0
5 MONITOR EEP DATA 0x 0
14/16 1 LCD TEST PATTERN OFF Pattern with built-in LCD controller display
15/16 1 READ/WRITE READ
2 SLAVE ADDRESS SLAVE0
3 REGISTER ADDRESS 0x 0
0x 0
4WRITE DATA 0x 0
0x 0
5 READ DATA 0x 0
0x 0
16/16 1 EEP SAVE OFF Writing setting values to EEPROM.
2 EEP RECOVER OFF Reading setting values from EEPROM.
3 MONITOR ERROR CAUSE RESET OFF
4 STANDBY CAUSE RESET OFF Reset stand by cause.
5 MODEL NAME D65
6 PANEL SIZE 32
7 PRODUCT EEP ADR 0x 0
8 PRODUCT EEP DATA 0x 0
Page Line Item Description Remarks (adjustment detail, etc.)
