Sharp LC-32D65E Service Manual

LC-32D65E/RU, LC-37D65E/RU
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
L2618 RCiLFA119WJZZY AE J Coil CILFA119WJ
L7508 VPSBN100J1R2NY AB J Coil Peaking 10µH
L8103 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
L9601 RCiLPA758WJQZY AC R Coil CILPA758WJ
L9603 RCiLPA762WJQZY AE J Coil CILPA762WJ
L9605 RCiLPA888WJZZY AG J Coil CILPA888WJ
L9606 RCiLFA228WJZZY AD J Coil CILFA228WJ
L9607 RCiLPA887WJZZY AG J Coil CILPA887WJ
LUG501 QLUGHA009WJZZY AC J Lug
LUG502 QLUGHA009WJZZY AC J Lug
LUG503 QLUGHA009WJZZY AC J Lug
LUG504 QLUGHA009WJZZY AC J Lug
LUG505 QLUGHA009WJZZY AC J Lug
LUG506 QLUGHA009WJZZY AC J Lug
LUG507 QLUGHA009WJZZY AC J Lug
LUG508 QLUGHA009WJZZY AC J Lug
P1301 QPLGNA160WJZZY AD J Plug 4Pin(SP)
P2003 QPLGNA330WJZZY AD J Plug 10Pin(RA)
P2603 QPLGNA329WJZZY AD J Plug 9Pin(LB)
P4401 QCNCMA318WJSA AN N R Plug
P8103 QPLGNA144WJZZY AF J Plug 20Pin(PARTNER)
P9601 QPLGNA168WJZZY AF J Plug 12Pin(PD)
P9603 QPLGNA335WJZZY AD J Plug 15pin (LP)
Q501 VSKRC404E++-1Y AB J Transistor KRC404E
Q502 VSDTC314TK/-1Y AC J Transistor DTC314TKT146
Q503 VSDTC314TK/-1Y AC J Transistor DTC314TKT146
Q504 VSDTC314TK/-1Y AC J Transistor DTC314TKT146
Q505 VSDTC314TK/-1Y AC J Transistor DTC314TKT146
Q510 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q511 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q512 VSDTC314TK/-1Y AC J Transistor DTC314TKT146
Q513 VSDTC314TK/-1Y AC J Transistor DTC314TKT146
Q1301
VSiMH23T110-1Y AC J Transistor IMH23T110
Q1504 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1506 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1516 VSiMD2A////-1Y AC J Transistor IMD2AT108
Q1802 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1803 VSDTA124EKA-1Y AB J Transistor DTA124EKAT146
Q1808 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1809 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q2002 VSRN1102///-1Y AB J Transistor RN1102(TE85L,F)
Q2003 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q4401 RH-TXA026WJZZY AD J Transistor PBLS2001D,115
Q5301 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q7503 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q7504 VSDTA124EKA-1Y AB J Transistor DTA124EKAT146
Q7505 RH-TXA026WJZZY AD J Transistor PBLS2001D,115
Q8703 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q9102 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q9602 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q9604 VSFW808ME++-1Y AE J Transistor FW808-M-TL-E
Q9605 VSRT1N144U/-1Y AB J Transistor RT1N144U-T111-1
Q9606 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q9607 VSEMZ1+++++-1Y AC J Transistor EMZ1T2R
Q9608 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q9609 VSDTA124EKA-1Y AB J Transistor DTA124EKAT146
R501 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R502 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R503 VRS-CZ1JF682JY AA J Resistor 6.8k 1/16W Metal Oxide
R504 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R505 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R506 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R507 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R508 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R509 VRS-TQ2EF680JY AA J Resistor 68 1/4W Metal Oxide
R510 VRS-TQ2EF680JY AA J Resistor 68 1/4W Metal Oxide
R511 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R512 VRS-CZ1JF682JY AA J Resistor 6.8k 1/16W Metal Oxide
R513 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R514 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R515 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R516 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R517 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R518 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R519 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R520 VRS-TQ2EF101JY AA J Resistor 100 1/4W Metal Oxide
R521 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R522 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R523 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R524 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R525 VRS-CZ1JF473JY AA J Resistor 47k 1/16W Metal Oxide
R526 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R527 VRS-TQ2EF101JY AA J Resistor 100 1/4W Metal Oxide
R528 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R529 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
[4] DUNTKE685FM01/FM03 (MAIN Unit)
