4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] CABINET AND MECHANICAL PARTS
1 CCABAC243WJ08 N P Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - LED Cover
1-3 Not Available - N - Decoration
1-4 XEBS730P08000 AA J Screw
2 CCABBB470WJ01 BA N P Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - - VESA Holder, x4
2-3 Not Available - N - Spacer (0.5x10x30), x6
2-4 XEBS730P08000 AA J Screw (for VESA), x4
3 CANGKC130WJ01 AK P Terminal Angle Ass'y
3-1 Not Available - - Terminal Label
3-2 Not Available - - Terminal Angle
4 CANGKC165WJ02 AS N P
Stand Angle Ass'y
4-1 Not Available - N -
Support Angle
4-2 Not Available - N -
Bottom Angle
4-3 Not Available - N - Screw (4x55), x4
5 JBTN-A812WJ1A AE N P Control Button
6 LANGKC138WJFW AF N P AC Inlet Angle
7 LHLDFA036WJKZ AB J Wire Holder, x4
8 LHLDWA143WJKZ AC J Wire Holder
9 LHLDWA175WJUZ AC J Wire Holder
10 LX-HZA003WJFN AC J Screw (for Speaker), x2
11 NSFTZA243WJFN AB J Shaft, x4
12 PSLDMB578WJFW AL N P Main PWB Shield
14 PSPAKA423WJKZ AA N P Spacer (0.3x3x8)
15 PSPANA032WJKZ AC J Spacer (for PWB)
16 QCNW-J026WJQZ AH J Connecting Cord (KM)
17 QCNW-J088WJQZ AK J Connecting Cord
18 QCNW-J206WJQZ AH N P Connecting Cord (LP)
19 QCNW-J207WJQZ AY N P Connecting Cord (LW)
20 QCNW-J208WJQZ AK N P Connecting Cord (LB)
21 QCNW-J211WJQZ AG N P
Connecting Cord, x2
22 QCNW-J550WJPZ AH N P Connecting Cord (SP)
23 QEARPA339WJFW AC P Earth Plate
24 RCORFA064WJZZ AE P Core (for LCD FFC), x2
25 RSP-ZA391WJZZ AP J Speaker-L
26 RSP-ZA392WJZZ AP J Speaker-R
27 TLABNC117WJZZ AA P Model Label
28 TLABZB406WJZZ AC P ECO Label (for Europe)
29 TLABZC169WJZZ AF N P POP Label (for Europe)
29 TLABZC170WJZZ AF N P POP Label (for Russia)
30 XBBS730P04000 AA J Screw (for Tuner)
31 XBPS830P06000 AA J Screw (for HDMI), x3
32 XEBS730P08000 AA J Screw, x2
33 XEBS740P16000 AA P Screw (for Rear Cabinet), x9
34 XEBSN40P10000 AB N J Screw (for LCD Module), x6
35 XHPS730P06WS0 AA J Screw (for PWB Angle), x25
LC-32DH57E-GY/RU-GY/S-GY
36 PSPAKA425WJKZ P Spacer (for RS232C Terminal)
N
37 XHPS730P08WS0 AA J Screw (for Rear Cabinet), x3
AV
BD
