LC-32/42/46DH77E/RU/S
3 – 4
6/16 [COMP15KMAIN]
1 COMP15K ALL ADJ Enter Component 15K picture level adjustment
2 COMP15K MAIN Y GAIN 141 Y GAIN adjustment value
3 COMP15K MAIN CB GAIN 150 Cb GAIN adjustment value
4 COMP15K MAIN CR GAIN 150 Cr GAIN adjustment value
5 COMP15K Y OFFSET 64 Y OFFSET adjustment value
6 COMP15K CB OFFSET 128 Cb OFFSET adjustment value
7 COMP15K CR OFFSET 128 Cr OFFSET adjustment value
7/16 [HDTV]
1 HDTV ADJ Enter HDTV video level adjustment
2 HDTV Y GAIN 141 HDTV Y GAIN adjustment value
3 HDTV CB GAIN 150 HDTV Cb adjustment value
4 HDTV CR GAIN 150 HDTV Cr adjustment value
5 HDTV Y OFFSET 64 HDTV Y OFFSET adjustment value
6 HDTV CB OFFSET 128 HDTV Cb OFFSET adjustment value
7 HDTV CR OFFSET 128 HDTV Cr OFFSET adjustment value
8/16 [ANALOG PC]
1 ANALOG PC ADJ Enter DVI ANALOG video level adjustment
2 R OFFSET 64 R CUTOFF adjustment value
3 G OFFSET 64 G CUTOFF adjustment value
4 B OFFSET 64 B CUTOFF adjustment value
5 R GAIN 44 R DRIVE adjustment value
6 G GAIN 44 G DRIVE adjustment value
7 B GAIN 44 B DRIVE adjustment value
9/16 [SCART]
1 SCART RGB ADJ Enter SCART RGB level adjustment
2 SCART R CUTOFF 64 SCART R CUTOFF adjustment value
3 SCART G CUTOFF 64 SCART G CUTOFF adjustment value
4 SCART B CUTOFF 64 SCART B CUTOFF adjustment value
5 SCART R GAIN 44 SCART R GAIN adjustment value
6 SCART G GAIN 44 SCART G GAIN adjustment value
7 SCART B GAIN 44 SCART B GAIN adjustment value
10/16 [LUMAADJ]
1 VCOM ADJ 0 Common bias adjustment
2 LCD LUMA ADJ Enter Upper and lower brightness difference adjustment
3LCD LUMA UP 0
4LCD LUMA DOWN 0
11/16 [FR DDRTEST]
1 DDRA TEST1 Enter Execute DDRA test 1
2 DDRA TEST2 Enter Execute DDRA test 2
3 DDRB TEST1 Enter Execute DDRA test 1
4 DDRB TEST2 Enter Execute DDRA test 2
5 DDRB TEST3 Enter Execute DDRA test 3
6 FRC ON/OFF Enter Execute FRC ON/OFF
7 SOUSAM DDR BIST Enter
8 SOUSAS DDR BIST Enter
12/16 [LEV]
1 R GAIN (LO) 0 R DRIVE adjustment value
2 G GAIN (LO) 0 G DRIVE adjustment value
3 B GAIN (LO) 0 B DRIVE adjustment value
4 R GAIN (HI) 0 R DRIVE adjustment value
5 G GAIN (HI) 0 G DRIVE adjustment value
6 B GAIN (HI) 0 B DRIVE adjustment value
13/16 [M EEP SET]
1 MONITOR TIME OUT ON Monitor and the main communication time-out setting
2 MONITOR MAX TEMP 32 MONITOR MAX temperature setting
3 MONITOR EEP READ / WRITE WRITE MONITOR EEPROM READ/WRITE Setting/execution
4 MONITOR EEP ADR 0x 0 MONITOR EEPROM arbitrary addressing
5 MONITOR EEP DATA 0x 0 MONITOR EEPROM arbitrary data specification
14/16 [M TEST PATTERN]
1 LCD TEST PATTERN OFF Pattern with built-in LCD controller display
2 LCD AGI TEST PATTERN
3 LCD EVA TEST PATTERN
4 YEL TEST PATTERN
Page Line Item Description Remarks (adjustment detail, etc.)
