PARTS GUIDE

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these

parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used

for after sales service only.

The contents are subject to change without notice.

LC-32/42/46DH77E/RU/S

PartsGuide

[1] PRINTED WIRING BOARD

ASSEMBLIES (LC-32DH77E/RU/S)

[2] PRINTED WIRING BOARD

ASSEMBLIES (LC-42DH77E/RU/S)

[3] PRINTED WIRING BOARD

ASSEMBLIES (LC-46DH77E/RU/S)

[4] LCD PANEL

[5] DUNTKF190FM01 (MAIN Unit)

[6] CABINET PARTS

(LC-32DH77E/RU/S)

[7] LCD PANEL MODULE ASSEMBLY

(LC-32DH77E/RU/S)

[8] CABINET PARTS

(LC-42DH77E/RU/S)

[9] LCD PANEL MODULE ASSEMBLY

(LC-42DH77E/RU/S)

[10] CABINET PARTS

(LC-46DH77E/RU/S)

[11] LCD PANEL MODULE ASSEMBLY

(LC-46DH77E/RU/S)

CONTENTS

No. S59Z5LC32D77C

LCD COLOUR TELEVISION

MODELS

LC-32DH77E/RU/S

LC-42DH77E/RU/S

LC-46DH77E/RU/S

Sharp LC-32DH77E Service Manual

Other manuals for Sharp LC-32DH77E
