Sharp LC-32DH77E Service Manual

LC-32/42/46DH77E/RU/S
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (LC-32DH77E/RU/S)
N DUNTKF190FM01 CE N P MAIN Unit (B3KUXH77CG)
N DUNTKF096FM04 AR N P LED Unit (B3KUXH77CJ)
!
N RUNTKA456WJQZ BT N P POWER/INVERTER Unit (Unit Replacement Item)
[2] PRINTED WIRING BOARD ASSEMBLIES (LC-42DH77E/RU/S)
N DUNTKF190FM01 CE N P MAIN Unit (B3KUXH77CG)
N DUNTKF096FM04 AR N P LED Unit (B3KUXH77CJ)
N DUNTKE266FM17 AL N P KEY Unit (B3KUXH77CK)
!
N RDENCA322WJQZ BP N P POWER Unit (Unit Replacement Item)
N RUNTKA534WJZZ BP J INVERTER Unit (Unit Replacement Item)
[3] PRINTED WIRING BOARD ASSEMBLIES (LC-46DH77E/RU/S)
N DUNTKF190FM01 CE N P MAIN Unit (B3KUXH77CG)
N DUNTKF096FM04 AR N P LED Unit (B3KUXH77CJ)
N DUNTKE266FM17 AL N P KEY Unit (B3KUXH77CK)
!
N RDENCA308WJQZ BR P POWER Unit (Unit Replacement Item)
N RUNTKA538WJZZ BF J INVERTER (1) Unit (Unit Replacement Item)
N RUNTKA539WJZZ BF J INVERTER (2) Unit (Unit Replacement Item)
[4] LCD PANEL
N R1LK315D3LW40Y N P 32" LCD Panel Module
N R1LK420D3LW80Y DN N P 42" LCD Panel Module
N R1LK460D3LW80Y DX N P 46" LCD Panel Module
[5] DUNTKF190FM01 (MAIN Unit)
C501 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C502 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C503 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C507 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C508 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C511 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C519 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C520 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C521 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C522 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C523 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C524 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C525 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C526 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C527 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C528 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C529 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C530 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C531 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C532 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C533 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C534 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C535 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C536 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C537 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C538 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C539 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C540 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C541 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C542 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C543 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C544 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C545 RC-KZA510WJPZY AB J
Capacitor 10 16V Ceramic
C546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C547 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C548 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C549 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C550 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C551 VCERMZ1CN477MY AE J Capacitor 470 16V Capacitor(AL)
C553 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C556 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C557 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C558 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C559 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C560 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C562 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C564 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C565 VCKYCZ1EB472KY AB J Capacitor 4700p 25V Ceramic
C566 VCKYCZ1EB472KY AB J Capacitor 4700p 25V Ceramic
C567 VCEASY1EN107MY AC J Capacitor 100 25V Electrolytic
C568 VCEASY1EN107MY AC J Capacitor 100 25V Electrolytic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 RC-KZA067WJZZY AB J Capacitor 4.7 10V Ceramic
C571 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C572 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C573 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
