Sharp LC-32DH77E Service Manual

LC-32/42/46DH77E/RU/S
9
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
L9606 RCiLPA759WJQZY AD J Coil
LUG9601 QLUGHA009WJZZY AC J Lug
LUG9602 QLUGHA009WJZZY AC J Lug
LUG9603 QLUGHA009WJZZY AC J Lug
LUG9604 QLUGHA009WJZZY AC J Lug
LUG9605 QLUGHA009WJZZY AC J Lug
LUG9606 QLUGHA009WJZZY AC J Lug
LUG9607 QLUGHA009WJZZY AC J Lug
LUG9608 QLUGHA009WJZZY AC J Lug
P2001 QPLGN0064CEZZY AE J Plug
P2002 QPLGNA324WJZZY AC J Plug
P2003 QPLGNA330WJZZY AD J Plug
P2601 QCNCWA671WJQZY AH J Plug
P2602 QPLGNA335WJZZY AD J Plug
P2603 QPLGNA144WJZZY AF J Plug
P2701 QPLGNA160WJZZY AD J Plug
P3301 QPLGNA144WJZZY AF J Plug
P9601 QPLGNA168WJZZY AF J Plug
P9602 QPLGNA329WJZZY AD J Plug
Q501 VSiMH23T110-1Y AC J Transistor IMH23T110
Q502 VSiMH23T110-1Y AC J Transistor IMH23T110
Q503 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q504 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q505 VSLTC144EEB-1Y AA J Transistor LTC144EEBFS8TL
Q506 VSiMH23T110-1Y AC J Transistor IMH23T110
Q507 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q508 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q509 VSiMH23T110-1Y AC J Transistor IMH23T110
Q1101 RH-TXA026WJZZY AD J Transistor PBLS2001D,115
Q1102 VSLTA124EEB-1Y AA J Transistor LTA124EEBFS8TL
Q1103 VSLTC144EEB-1Y AA J Transistor LTC144EEBFS8TL
Q1104 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q1106 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1508 VSKTA1535T+-1Y AC J
Transistor KTA1535T-RTK/P
Q1509 VSKRC402E++-1Y AB J Transistor
Q2003 VSRT1P141U/-1Y AB J Transistor RT1P141U-T111-1
Q2004 VSRT1N141U/-1Y AB J Transistor RT1N141U-T111-1
Q2005 VSRN1102///-1Y AB J Transistor RN1102(TE85L,F)
Q2006 VSRT1N141U/-1Y AB J Transistor RT1N141U-T111-1
Q2603 VSLTC144EEB-1Y AA J Transistor LTC144EEBFS8TL
Q2701 VSDTC614TK+-1Y AB J Transistor DTC614TKT146
Q9601 VSLTC144EEB-1Y AA J Transistor LTC144EEBFS8TL
Q9602 VSLTA124EEB-1Y AA J Transistor LTA124EEBFS8TL
Q9604 RH-TXA026WJZZY AD J Transistor PBLS2001D,115
Q9607 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q9608 VSLTC144EEB-1Y AA J Transistor LTC144EEBFS8TL
Q9609 VSLTA124EEB-1Y AA J Transistor LTA124EEBFS8TL
Q9610 VSRSS050P03-1Y AG J Transistor RSS050P03TB
R504 VRS-CZ1JF103FY AB J Resistor 10k 1/16W Metal Oxide
R505 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R506 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R507 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R508 VRS-CZ1JF333FY AA J Resistor 33k 1/16W Metal Oxide
R511 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R512 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R513 VRS-TQ2EF680JY AA J Resistor 68 1/4W Metal Oxide
R514 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R515 VRS-CZ1JF103FY AB J Resistor 10k 1/16W Metal Oxide
R516 VRS-TQ2EF101JY AA J Resistor 100 1/4W Metal Oxide
R517 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R518 VRS-TQ2EF680JY AA J Resistor 68 1/4W Metal Oxide
R519 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R520 VRS-CZ1JF333FY AA J Resistor 33k 1/16W Metal Oxide
R522 VRS-CZ1JF221JY AA J Resistor 220 1/16W Metal Oxide
R523 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R524 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R530 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R531
VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R533 VRS-CZ1JF221JY AA J Resistor 220 1/16W Metal Oxide
R535 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R537 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R538 VRK-SA1JF472JY AA J Resistor 4.7k 1/16W Metal Composition
R541 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R544 VRS-TQ2EF750JY AA J Resistor 75 1/4W Metal Oxide
R547 VRS-CG1JF101JY AA J Resistor 100 1/16W Metal Oxide
R549 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R550 VRS-CZ1JF221JY AA J Resistor 220 1/16W Metal Oxide
R551 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R552 VRS-TV1JD221JY AA J Resistor 220 1/10W Metal Oxide
R553 VRS-TV1JD221JY AA J Resistor 220 1/10W Metal Oxide
R554 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R555 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R556 VRS-TV1JD221JY AA J Resistor 220 1/10W Metal Oxide
R557 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R558 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
[5] DUNTKF190FM01 (MAIN Unit)
