Sharp LC-32DH77E Service Manual

LC-32/42/46DH77E/RU/S
15
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R9658 VRS-CZ1JF153FY AA J Resistor 15k 1/16W Metal Oxide
R9664 VRS-CZ1JF105JY AA J Resistor 1M 1/16W Metal Oxide
R9665 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9666 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9669 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9681 VRS-CZ1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R9684 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R9685 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
S2001 QSW-KA037WJZZY AC J Switch
S2002 QSW-KA037WJZZY AC J Switch
S2003 QSW-KA037WJZZY AC J Switch
S2004 QSW-KA037WJZZY AC J Switch
S2005 QSW-KA037WJZZY AC J Switch
S2006 QSW-KA037WJZZY AC J Switch
S2007 QSW-KA037WJZZY AC J Switch
SC501 QSOCNA716WJZZ AM J Socket
SC502 QSOCZA161WJZZ AG J Socket
SC503 QSOCZA161WJZZ AG J Socket
SC504 QSOCNA715WJZZ AL J Socket
SC1501 QSOCZA072WJZZQ AH J Socket
SC1502 QSOCZA171WJZZY AF J Socket
SC1503 QSOCZA171WJZZY AF J Socket
TH2001 VHHM1103J03-1Y AC J Thermistor
!
TU1101 RTUDAA019WJQZ AZ J Tuner
VA501 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA502 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA503 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA506 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA507 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA508 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA509 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA510 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABBG
VA3301 RH-VXA074WJZZY AB J Varistor AVRL101A1R1NTB
VA3302 RH-VXA074WJZZY AB J Varistor AVRL101A1R1NTB
X2001 RCRSC0032TAZZY AG J Crystal
X2002 RFiLZA023WJQZY AD J Crystal Filter
X3302 RCRSCA101WJZZY AG J Crystal
X4401 RCRSCA101WJZZY AG J Crystal
N PCOVZA132WJKA N J Cover
[5] DUNTKF190FM01 (MAIN Unit)
