Sharp LC-32DH77E Service Manual

LC-32/42/46DH77E/RU/S
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[6] CABINET PARTS (LC-32DH77E/RU/S)
1 CCABAC191WJ04 P Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - Bottom Dec-A Ass'y
1-2-1 Not Available - N - Bottom Dec-A
1-3 Not Available - N - Bottom Dec-B Ass'y
1-3-1 Not Available - N - Bottom Dec-B
1-3-2 Not Available - N - Shine Trim
1-4 Not Available - N - LED Decoration
1-5 XEBS930P10000 AA J Screws, x9 (Front Dec.)
2 CCABBB390WJ01 BL P Back Cabinet Ass'y
2-1 Not Available - N - Back Cabinet
2-2 Not Available - N - Terminal Label
2-3 Not Available - - VESA Angle, x4
2-4 XEBS930P08000 AA J Screws, x4 (VESA Holder)
3 CCOVAD195WJ01 AU P Control Cover Ass'y
3-1 Not Available - N - Control Cover
3-2 Not Available - N - Control Label
3-3 Not Available - N - SIDE AV Label
4 GCOVAD184WJ1A AK P Bottom Cover
6 LANGKB569WJFW AC P LCD Angle A
7 LANGKB570WJFW AC P LCD Angle B
8 LANGKB597WJFW AL P Panel Support Angle, x2
9 LANGKB970WJFW AM P Stand Angle
10 LHLDWA143WJKZ AC J Wire Holder (Cable)
11 LHLDFA062WJKZ J Wire Holder (Power PWB)
12 LHLDZB300WJ1A AF P LCD Holder A
13 LHLDZB301WJ1A AF P LCD Holder B
14 LX-WZA053WJZZ AN P Washer (Power)
15 NSFTZA237WJFN AC J Screw, x4 (D-Sub)
16 PSLDMB475WJFW AN P Full Shield
17 PSLDMB516WJN0 AH P T-CON Shield
18 PSPAZB313WJKZ AC J Spacer (TCON)
19 PSPAZB864WJKZ AG J Spacer
20 PSPAZC237WJKZ AH N P
Cooling Sheet, x2
21 PSPAZC312WJKZ P Cooling Sheet, x2
22 QCNW-H330WJQZ AH P Connecting Cord (LB)
23 QCNW-J286WJQZ AM P Connecting Cord (PD)
24 QCNW-H844WJQZ AK P Connecting Cord (RA)
25 QCNW-J550WJPZ AH P Connecting Cord (SP)
26 QCNW-H846WJQZ AL P Connecting Cord (LP)
27 QCNW-H847WJQZ AZ P Connecting Cord (LW)
28 RCORF0103CEZZ AK J Core (SP Wire)
29 RCORFA023WJZZ AK J Core
30 RSP-ZA421WJZZ AS P Speaker (L)
31 RSP-ZA422WJZZ AS P Speaker (R)
33 XBBS730P04000 AA J Screw (TUNER/SHIELD)
34 XBPS830P06000 AA J Screws, x3 (HDMI)
35 XEBS930P08000 AA J Screw (21PIN)
36 XEBS940P16000 AB J Screws, x10 (CAB-B)
37 XEBSN40P10000 AB J Screws, x4 (ANG-CAB-A)
38 XHPS730P06WS0 AA J Screws, x35 (ANG/PWB )
39 XHPS730P10WS0 AA P Screw (MAIN PWB)
40 TLABNC117WJZZ AB P Model Label
41 TLABZB406WJZZ AC P EU ECO Label (LC-32DH77E/S)
