LC-32/42/46DH77E/RU/S
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] LCD PANEL MODULE ASSEMBLY (LC-32DH77E/RU/S)
1 R1LK315D3LW40Y N P 32" LCD Panel Module
2 CANGK4055TP0D AP J Bezel Ass'y (Top)
3 CANGK4055TP0E AT J Bezel Ass'y (Bottom)
4 CANGKC106WJ01 AF J Gate Protector Ass'y, x2
5 CHLDZB360WJ01 AP J Panel Chassis Ass'y (Top)
6 CHLDZB361WJ01 AP J Panel Chassis Ass'y (Bottom)
7 PSHEPA864WJZZ AU J Lens Sheet
8 PSHEPA865WJZZ AQ J Diffusion Sheet
9 PCOVUA161WJZZ AV J Diffusion Plate
10 CHLDZB362WJ01 AN J Lamp Holder (L)
11 CHLDZB363WJ01 AP J Lamp Holder (R)
12 RLMP-0663TPZZ AS J Lamp Unit, x14
13 QSOCFA003WJZZ AD J Lamp Socket, x14
14 RUNTK3839TPZZ AM J GND-PWB
15 RUNTK3840TPZZ AM J GND-PWB
16 Not Available - - Back Light Chassis Ass'y
17 PCOVWA053WJKZ J SJ Connector Cover (Top)
18 PCOVWA054WJKZ J SJ Connector Cover (Bottom)
19 CPWBX4151TPXF J LCD Control PWB Unit
20 QPWBM0792TPZZ AL J CS FPC
21 QPWBM0793TPZZ AL J CS FPC
22 RCORFA061WJZZ AG J Ferrite Core, x4
23 LX-EZA028WJF9 AB J Screw, x10 (Bezel-Panel Chassis, x8/Gate Protector, x2)
24 XHPS730P04WS0 AA J Screw, x15 (SJ COVER, x5/C-PWB, x6/C-PWB Cover, x4)
25 XHPS730P08KS0 AB J Screw, x4 (M3X8 GND PWB)
26 LX-HZA039WJF7 AB J Screw, x6 (BL Chassis-Bezel)
27 LX-HZA047WJF7 AB J Screw, x4 (BL Chassis-Bezel)
28 LANGKB978WJFW AH J LCD Control PWB Attachment Angle
